9105-41B EPG2 IBM S1014 Power10 8-Core Processor P10 System
The IBM S1014 9105-41B EPG2 is a 8-Core Power10 Processor that is in a P10 Software Tier, delivers 205,300 CPW, can have up to 1 TB of DDR4 memory in 8 DDIMM slots, 102.4 TB of NVMe flash storage, and supports IBM i OS400, AIX, VIOS and Linux Server operating systems. The IBM Power10 S1024 9105-42A system is the most reliable and secure scale-out server in its class, and now extends that leadership to hybrid cloud environments with its ability to encrypt all data without burdening management costs or impacting performance, while also taking advantage of workload deployment flexibility.
IBM S1014 Brochure | 9105-41B Data Sheet | Power10 CPW rPerf Performance Benchmarks | IBM i Power10 Performance Optimization | Power10 versus Power9 P05 Comparison
Other IBM Power10 System Models by specification maximums:
IBM S1014 9105-41B: 1 socket, 8 Cores, 1 TB Memory, 102.4 TB NVMe flash storage (16 bays), 4U
IBM S1022 9105-22A: 2 socket, 40 Cores, 4 TB Memory, 51.2 TB NVMe flash storage (8 bays), 2U
IBM S1022s 9105-22B: 2 socket, 16 Cores, 2 TB Memory, 51.2 TB NVMe flash storage (8 bays), 2U
IBM S1024 9105-42A: 2 socket, 48 Cores, 8 TB Memory, 102.4 TB of NVMe flash storage (16 bays), 4U
IBM E1050 9043-MRX: 4 socket, 96 Cores, 16 TB Memory, 64 TB of NVMe flash storage (10 bays), 4U
IBM E1080 9080-HEX: 16 socket, 240 Cores, 34 TB Memory, 102.4 TB NVMe flash storage (16 bays), 6U
IBM Power10 S1014 Server Configuration Options
IBM S1014 Power10 Processor Performance Specifications
9105-41B EPG0 4-core 3-3.9 Ghz Processor, P05: 106,300 CPW | 38.6 76.4 102.6 129.4 rPerf
9105-41B EPG2 8-core 3-3.9 Ghz Processor, P10: 205,300 CPW | 77.2 149.1 198.8 254.2 rPerf
8 DDIMM slots for up to 1 TB of extremely high-performance, high-reliability, intelligent, and dynamic random access memory (DRAM) devices.
IBM EM6N 32 GB (2 x 16 GB) DDIMMs, 3200 MHz, 8 Gb DDR4 Memory
IBM EM6W 64 GB (2 x 32 GB) DDIMMs, 3200 MHz, 8 Gb DDR4 Memory
IBM EM6X 128 GB (2 x 64 GB) DDIMMs, 3200 MHz, 16 Gb DDR4 Memory
IBM EM6Y 256 GB (2 x 128 GB) DDIMMs, 2933 MHz, 16 Gb DDR4 Memory
Note: The IBM EM6Y 256 GB (2 x 128 GB) DDIMMs are unavailable until November 18th 2022, so until maximum memory capacity of an 8-core S1014 server is 512 GB until this date.
Cache Memory:
L2 cache: 2 MB (private access of core)
L3 cache: 8 MB (accessible by all cores, 120 MB is maximum)
5 PCIe slots with single processor (all concurrently maintainable):
One PCIe x16 Gen4 or x8 Gen5, full-height, half-length slot
Three PCIe x8 Gen5, full-height, half-length slots (with x16 connector)
One PCIe x8 Gen4, full-height, half-length slot(with x16 connector)
Integrated:
System management using an Enterprise Baseboard Management Controller (eBMC).
EnergyScale technology.
Redundant hot-swap cooling.
Redundant hot-swap AC power supplies.
Up to two HMCs with 1 GbE RJ45 ports.
One rear USB 3.0 port.
One front USB 3.0 port.
One internal USB 3.0 Port for RDX.
Nineteen-inch rack-mounting hardware (4U).
Other Key Features:
Capacity Upgrade on Demand (CUoD) activation core features
IBM Private Cloud with Dynamic Capacity for Enterprise Pools 2.0 activation core features
In-core AI inferencing and machine learning with Matrix Math Accelerator (MMA) feature.
Transparent Memory Encryption with no additional management setup and no performance impact
Active Memory Mirroring (AMM) for Hypervisor available as an option to enhance resilience by mirroring critical memory used by the IBM PowerVM hypervisor
Optional internal RDX drive
2+2 redundant hot-plug AC Titanium power supplies in each enclosure
PowerVM-integrated virtualization with minimum processing overhead
Capacity Upgrade on Demand (CUoD) processor activation entitlement
IBM Private Cloud with Dynamic Capacity for Enterprise Pools 2.0 processor activation entitlement
Optional PCIe I/O expansion drawer with PCIe slots
Up to one PCIe Gen3 I/O Expansion drawer (EMX0) that holds one six-slot PCIe fanout modules (EMXH). The EMX0 fanout module attaches to the system node through a PCIe optical or copper cable adapter (EJ2A).
IBM S1014 9105-41B NVMe Flash Storage options for IBM i
IBM 594A PCIe4 1.6 TB NVMe Flash Adapter x8 02DE956 EC7K for IBM i
IBM 594B PCIe4 3.2 TB NVMe Flash Adapter x8 02DE960 EC7M for IBM i
IBM 594C PCIe4 6.4 TB NVMe Flash Adapter x8 02DE964 EC7P for IBM i
IBM 58FC PCIe3 x8 1.6 TB NVMe Flash Adapter 01DH570 EC6V for IBM i
IBM 58FD PCIe3 x8 3.2 TB NVMe Flash Adapter 01LK431 EC6X for IBM i
IBM 58FE PCIe3 x8 6.4 TB NVMe Flash Adapter 01LK435 EC6Z for IBM i
IBM S1014 9105-41B Enterprise Class SSD loptions for IBM i
IBM 59BA PCIe4 6.4 TB Enterprise SSD NVMe U.2 module 01LU969 EC5W for IBM i
IBM 5B53 PCIe4 800 GB Enterprise SSD NVMe U.2 module 02YC724 02YC738 ES3A EKF2 for IBM i
IBM 59B8 PCIe4 1.6 TB Enterprise SSD NVMe U.2 module 01LU967 ES1F for IBM i
IBM 59B9 PCIe4 3.2 TB Enterprise SSD NVMe U.2 module 01LU968 ES1H for IBM i
IBM 5947 PCIe4 800GB Enterprise SSD NVMe U.2 module 01LU973 ES1K for IBM i
IBM 5B52 PCIe4 1.6 TB Enterprise SSD NVMe U.2 module 02YC725 02YC739 ES3C for IBM i
IBM 5B51 PCIe4 3.2 TB Enterprise SSD NVMe U.2 module 02YC726 02YC740 ES3E for IBM i
IBM 5B50 PCIe4 6.4 TB Enterprise SSD NVMe U.2 module 02YC727 02YC741 ES3G EKF7 for IBM i
IBM S1014 9105-41B Mainstream SSD options for IBM i
IBM 5B29 PCIe3 931GB Mainstream SAS 4k SFF-2 SSD 00LY553 01LU802 01LU898 02YC591 02YC642 02YC701 ESJ1 for IBM i
IBM S1014 9105-41B NVMe Flash Storage options for AIX and Linux
IBM 594A PCIe4 1.6 TB NVMe Flash Adapter x8 02DE956 EC7B for AIX Linux
IBM 594B PCIe4 3.2 TB NVMe Flash Adapter x8 02DE960 EC7D for AIX Linux
IBM 594C PCIe4 6.4 TB NVMe Flash Adapter x8 02DE964 EC7F for AIX Linux
IBM 58FC PCIe3 x8 1.6 TB NVMe Flash Adapter 01DH570 EC5A EC5B for AIX Linux
IBM 58FD PCIe3 x8 3.2 TB NVMe Flash Adapter 01LK431 EC5D for AIX Linux
IBM 58FE PCIe3 x8 6.4 TB NVMe Flash Adapter 01LK435 EC5F for AIX Linux
IBM S1014 9105-41B Enterprise Class SSD options for AIX and Linux
IBM 5B52 PCIe4 1.6 TB Enterprise SSD NVMe U.2 module 02YC725 02YC739 ES3B for AIX Linux
IBM 59BA PCIe4 6.4 TB Enterprise SSD NVMe U.2 module 01LU969 EC5V for AIX Linux
IBM S1014 9105-41B Mainstream SSD options for AIX and Linux
IBM 59B7 PCIe3 800 GB Mainstream SSD NVMe U.2 module 02YC615 EC7T EC5X for AIX Linux
IBM 5B29 PCIe3 931GB Mainstream SAS 4k SFF-2 SSD 00LY553 01LU802 01LU898 02YC591 02YC642 02YC701 ESJ0 ESJ1 for AIX/Linux
IBM S1014 9105-41B System Requirements:
i OS400 IBM V7R5 or later
i OS400 IBM V7R4 TR6 or later
i OS400 IBM V7R3 TR12 or later
IBM AIX Version 7.3 with the 7300-00 Technology Level and Service Pack 7300-00-02-2220, or later
IBM AIX Version 7.2 with the 7200-05 Technology Level and Service Pack 7200-05-04-2220, or later
IBM AIX Version 7.2 with the 7200-04 Technology Level and Service Pack 7200-04-06-2220, or later
If AIX operating system is used on LPAR with Virtual I/O only, use the below AIX requirements:
AIX Version 7.3 with the 7300-00 Technology Level and service pack 7300-00-01-2148, or later
AIX Version 7.2 with the 7200-05 Technology Level and service pack 7200-05-01-2038, or later
AIX Version 7.2 with the 7200-04 Technology Level and Service Pack 7200-04-02-2016, or later
AIX Version 7.1 with the 7100-05 Technology Level and Service Pack 7100-05-06-2016, or later
IBM Red Hat Enterprise Linux Server 9.0, for Power LE, or later
IBM Red Hat Enterprise Linux 8.4, for Power LE, or later
SUSE Linux Enterprise Server 15 Service Pack 3, or later
SUSE Linux Enterprise Server for SAP with SUSE Linux Enterprise Server 15 Service Pack 3, or later
Red Hat Enterprise Linux for SAP with Red Hat Enterprise Linux 8.4 for Power LE, or later
Red Hat OpenShift Container Platform 4.9, or later
VIOS 3.1.3.21
19-inch rack-mount hardware Physical Specifications:
Width: 18.97 inches
Depth: 28 inches
Height: 6.8 inches (4U)
Weight: 80 lbs
Tower hardware Physical Specifications:
Width with stand: 13 inches
Depth with front-rotatable door: 32 inches
Height with handle: 20.6 inches
Weight: 105 lbs
