IBM Power10 9105-41B EPG2 IBM S1014 Power10 8-Core Processor P10 System The IBM S1014 9105-41B EPG2 is a 8-Core Power10 Processor that is in a P10 Software Tier, delivers 2.. Product #: S1014-9105-41B-EPG2

9105-41B EPG2 IBM S1014 Power10 8-Core Processor P10 System

Brand: IBM Power10
Model Number: S1014-9105-41B-EPG2

The IBM S1014 9105-41B EPG2 is a 8-Core Power10 Processor that is in a P10 Software Tier, delivers 205,300 CPW, can have up to 1 TB of DDR4 memory in 8 DDIMM slots, 102.4 TB of NVMe flash storage, and supports IBM i OS400, AIX, VIOS and Linux Server operating systems. The IBM Power10 S1024 9105-42A system is the most reliable and secure scale-out server in its class, and now extends that leadership to hybrid cloud environments with its ability to encrypt all data without burdening management costs or impacting performance, while also taking advantage of workload deployment flexibility.

Other IBM Power10 System Models include (by maximums):
IBM S1014 9105-41B: 1 socket, 8 Cores, 1 TB Memory, 102.4 TB NVMe flash storage (16 bays), 4U
IBM S1022 9105-22A: 2 socket, 40 Cores, 4 TB Memory, 51.2 TB NVMe flash storage (8 bays), 2U
IBM S1024 9105-42A: 2 socket, 48 Cores, 8 TB Memory, 102.4 TB of NVMe flash storage (16 bays), 4U
IBM E1050 9043-MRX: 4 socket, 96 Cores, 16 TB Memory, 64 TB of NVMe flash storage (10 bays), 4U
IBM E1080 9080-HEX: 16 socket, 240 Cores, 34 TB Memory, 102.4 TB NVMe flash storage (16 bays), 6U
IBM Power10 Virtual Server: flexible, custom, secure virtual server on premises or in cloud.

IBM Power10 S1014 Server Configuration Options

IBM S1014 Power10 Processor Performance Specifications
9105-41B EPG0 4-core 3-3.9 Ghz Processor, P05: 106,300 CPW | 38.6 76.4 102.6 129.4 rPerf
9105-41B EPG2 8-core 3-3.9 Ghz Processor, P10: 205,300 CPW | 77.2 149.1 198.8 254.2 rPerf

8 DDIMM slots for up to 1 TB of extremely high-performance, high-reliability, intelligent, and dynamic random access memory (DRAM) devices.
IBM EM6N 32 GB (2 x 16 GB) DDIMMs, 3200 MHz, 8 Gb DDR4 Memory
IBM EM6W 64 GB (2 x 32 GB) DDIMMs, 3200 MHz, 8 Gb DDR4 Memory
IBM EM6X 128 GB (2 x 64 GB) DDIMMs, 3200 MHz, 16 Gb DDR4 Memory
IBM EM6Y 256 GB (2 x 128 GB) DDIMMs, 2933 MHz, 16 Gb DDR4 Memory
Note: The IBM EM6Y 256 GB (2 x 128 GB) DDIMMs are unavailable until November 18th 2022, so until maximum memory capacity of an 8-core S1014 server is 512 GB until this date.

Cache Memory:
L2 cache: 2 MB (private access of core)
L3 cache: 8 MB (accessible by all cores, 120 MB is maximum)

5 PCIe slots with single processor (all concurrently maintainable):
One PCIe x16 Gen4 or x8 Gen5, full-height, half-length slot
Three PCIe x8 Gen5, full-height, half-length slots (with x16 connector)
One PCIe x8 Gen4, full-height, half-length slot(with x16 connector)

Integrated:
System management using an Enterprise Baseboard Management Controller (eBMC).
EnergyScale technology.
Redundant hot-swap cooling.
Redundant hot-swap AC power supplies.
Up to two HMCs with 1 GbE RJ45 ports.
One rear USB 3.0 port.
One front USB 3.0 port.
One internal USB 3.0 Port for RDX.
Nineteen-inch rack-mounting hardware (4U).

Other Key Features:
Capacity Upgrade on Demand (CUoD) activation core features

IBM Private Cloud with Dynamic Capacity for Enterprise Pools 2.0 activation core features
In-core AI inferencing and machine learning with Matrix Math Accelerator (MMA) feature.
Transparent Memory Encryption with no additional management setup and no performance impact
Active Memory Mirroring (AMM) for Hypervisor available as an option to enhance resilience by mirroring critical memory used by the IBM PowerVM hypervisor
Optional internal RDX drive
2+2 redundant hot-plug AC Titanium power supplies in each enclosure
PowerVM-integrated virtualization with minimum processing overhead
Capacity Upgrade on Demand (CUoD) processor activation entitlement
IBM Private Cloud with Dynamic Capacity for Enterprise Pools 2.0 processor activation entitlement

Optional PCIe I/O expansion drawer with PCIe slots
Up to one PCIe Gen3 I/O Expansion drawer (EMX0) that holds one six-slot PCIe fanout modules (EMXH). The EMX0 fanout module attaches to the system node through a PCIe optical or copper cable adapter (EJ2A).

IBM Power10 Storage NVMe, SSD and HDD Feature Options
IBM EC7K PCIe4 1.6 TB NVMe Flash Adapter x8 for IBM i
IBM EC7M PCIe4 3.2 TB NVMe Flash Adapter x8 for IBM i
IBM EC7P PCIe4 6.4 TB NVMe Flash Adapter x8 for IBM i
IBM EC5W PCIe4 6.4 TB SSD NVMe U.2 Enterprise module for IBM i
IBM EC6V PCIe3 x8 1.6 TB NVMe Flash Adapter for IBM i
IBM EC6X PCIe3 x8 3.2 TB NVMe Flash Adapter for IBM i
IBM EC6Z PCIe3 x8 6.4 TB NVMe Flash Adapter for IBM i
IBM ES1F Enterprise 1.6 TB SSD PCIe4 NVMe U.2 module for IBM i
IBM ES1H Enterprise 3.2 TB SSD PCIe4 NVMe U.2 module for IBM i
IBM ES1K Enterprise 800GB SSD PCIe4 NVMe U.2 module for IBM i
IBM ES3A Enterprise 800GB SSD PCIe4 NVMe U.2 module for IBM i
IBM ES3C Enterprise 1.6 TB SSD PCIe4 NVMe U.2 module for IBM i
IBM ES3E Enterprise 3.2 TB SSD PCIe4 NVMe U.2 module for IBM i
IBM ES3G Enterprise 6.4 TB SSD PCIe4 NVMe U.2 module for IBM i
IBM ES95 387GB Enterprise SAS 4k SFF-2 SSD for IBM i
IBM ESBB 387GB Enterprise SAS 4k SFF-2 SSD for IBM i
IBM ESBH 775GB Enterprise SAS 4k SFF-2 SSD for IBM i
IBM ESBM 1.55TB Enterprise SAS 4k SFF-2 SSD for IBM i
IBM ESEU 571GB 10K RPM SAS SFF- HDD 4K for IBM i
IBM ESF2 1.1TB 10K RPM SAS SFF-2 HDD 4K for IBM i
IBM ESFS 1.7TB 10K RPM SAS SFF-2 HDD 4K for IBM i
IBM ESJ1 931GB Mainstream SAS 4k SFF-2 SSD for IBM i
IBM ESJ3 1.86TB Mainstream SAS 4k SFF-2 SSD for IBM i
IBM ESJ5 3.72TB Mainstream SAS 4k SFF-2 SSD for IBM i
IBM ESJ7 7.45TB Mainstream SAS 4k SFF-2 SSD for IBM i
IBM ESJK 931GB Mainstream SAS 4k SFF-2 SSD for IBM i
IBM ESJM 1.86TB Mainstream SAS 4k SFF-2 SSD for IBM i
IBM ESJP 3.72TB Mainstream SAS 4k SFF-2 SSD for IBM i
IBM ESJR 7.44TB Mainstream SAS 4k SFF-2 SSD for IBM i
IBM ESK9 387GB Enterprise SAS 4k SFF-2 SSD for IBM i
IBM ESKD 775GB Enterprise SAS 4k SFF-2 SSD for IBM i
IBM ESKH 1.55TB Enterprise SAS 4k SFF-2 SSD for IBM i
IBM ESKM 931GB Mainstream SAS 4k SFF-2 SSD for IBM i
IBM ESKR 1.86TB Mainstream SAS 4k SFF-2 SSD for IBM i
IBM ESKV 3.72TB Mainstream SAS 4k SFF-2 SSD for IBM i
IBM ESKZ 7.44TB Mainstream SAS 4k SFF-2 SSD for IBM i
IBM EC7B PCIe4 1.6 TB NVMe Flash Adapter x8 for AIX Linux
IBM EC7D PCIe4 3.2 TB NVMe Flash Adapter x8 for AIX Linux
IBM EC7F PCIe4 6.4 TB NVMe Flash Adapter x8 for AIX Linux
IBM EC5V PCIe4 6.4 TB SSD NVMe U.2 Enterprise module for AIX Linux
IBM EC7T PCIe4 800 GB Mainstream NVMe U.2 SSD 4k for AIX Linux
IBM EC5B PCIe3 x8 1.6 TB NVMe Flash Adapter for AIX Linux
IBM EC5D PCIe3 x8 3.2 TB NVMe Flash Adapter for AIX Linux
IBM EC5F PCIe3 x8 6.4 TB NVMe Flash Adapter for AIX Linux
IBM EC5X PCIe3 800 GB Mainstream SSD NVMe U.2 module for AIX Linux
IBM EL1P 300GB 15k RPM SAS SFF-2 Disk Drive (Linux)
IBM EL1Q 600GB 10k RPM SAS SFF-2 Disk Drive (Linux
IBM ELEV 600GB 10K RPM SAS SFF-2 Disk Drive 4K Block
IBM ELF3 1.2TB 10K RPM SAS SFF-2 Disk Drive 4K Block
IBM ELFT 1.8TB 10K RPM SAS SFF-2 Disk Drive 4K Block
IBM ES1E Enterprise 1.6 TB SSD PCIe4 NVMe U.2 module for AIX Linux
IBM ES1G Enterprise 3.2 TB SSD PCIe4 NVMe U.2 module for AIX Linux
IBM ES3B Enterprise 1.6 TB SSD PCIe4 NVMe U.2 module for AIX Linux
IBM ES3D Enterprise 3.2 TB SSD PCIe4 NVMe U.2 module for AIX Linux
IBM ES3F Enterprise 6.4 TB SSD PCIe4 NVMe U.2 module for AIX Linux
IBM ES94 387GB Enterprise SAS 4k SFF-2 SSD for AIX Linux
IBM ESB2 387GB Enterprise SAS 5xx SFF-2 SSD for AIX Linux
IBM ESB6 775GB Enterprise SAS 5xx SFF-2 SSD for AIX Linux
IBM ESBA 387GB Enterprise SAS 4k SFF-2 SSD for AIX Linux
IBM ESBG 775GB Enterprise SAS 4k SFF-2 SSD for AIX Linux
IBM ESBL 1.55TB Enterprise SAS 4k SFF-2 SSD for AIX Linux
IBM ESEV 600GB 10K RPM SAS SFF-2 HDD 4K for AIX Linux
IBM ESF3 1.2TB 10K RPM SAS SFF-2 HDD 4K for AIX Linux
IBM ESFT 1.8TB 10K RPM SAS SFF-2 HDD 4K for AIX Linux
IBM ESGV 387GB Enterprise SAS 5xx SFF-2 SSD for AIX Linux
IBM ESGZ 775GB Enterprise SAS 5xx SFF-2 SSD for AIX Linux
IBM ESJ0 931GB Mainstream SAS 4k SFF-2 SSD for AIX Linux
IBM ESJ2 1.86TB Mainstream SAS 4k SFF-2 SSD for AIX Linux
IBM ESJ4 3.72TB Mainstream SAS 4k SFF-2 SSD for AIX Linux
IBM ESJ6 7.45TB Mainstream SAS 4k SFF-2 SSD for AIX Linux
IBM ESJJ 931GB Mainstream SAS 4k SFF-2 SSD for AIX Linux
IBM ESJL 1.86TB Mainstream SAS 4k SFF-2 SSD for AIX Linux
IBM ESJN 3.72TB Mainstream SAS 4k SFF-2 SSD for AIX Linux
IBM ESJQ 7.44TB Mainstream SAS 4k SFF-2 SSD for AIX Linux
IBM ESK1 387GB Enterprise SAS 5xx SFF-2 SSD for AIX Linux
IBM ESK3 775GB Enterprise SAS 5xx SFF-2 SSD for AIX Linux
IBM ESK8 387GB Enterprise SAS 4k SFF-2 SSD for AIX Linux
IBM ESKC 775GB Enterprise SAS 4k SFF-2 SSD for AIX Linux
IBM ESKG 1.55TB Enterprise SAS 4k SFF-2 SSD for AIX Linux
IBM ESKK 931GB Mainstream SAS 4k SFF-2 SSD for AIX Linux
IBM ESKP 1.86TB Mainstream SAS 4k SFF-2 SSD for AIX Linux
IBM ESKT 3.72TB Mainstream SAS 4k SFF-2 SSD for AIX Linux
IBM ESKX 7.44TB Mainstream SAS 4k SFF-2 SSD for AIX Linux

IBM S1014 9105-41B System Requirements:
IBM i OS400 V7R5, or later
IBM i OS400 V7R4 TR6 or later
IBM i OS400 V7R3 TR12 or later

IBM AIX Version 7.3 with the 7300-00 Technology Level and Service Pack 7300-00-02-2220, or later
IBM AIX Version 7.2 with the 7200-05 Technology Level and Service Pack 7200-05-04-2220, or later
IBM AIX Version 7.2 with the 7200-04 Technology Level and Service Pack 7200-04-06-2220, or later
If installing the AIX operating system with Virtual I/O only LPAR (one of these):
AIX Version 7.3 with the 7300-00 Technology Level and service pack 7300-00-01-2148, or later
AIX Version 7.2 with the 7200-05 Technology Level and service pack 7200-05-01-2038, or later
AIX Version 7.2 with the 7200-04 Technology Level and Service Pack 7200-04-02-2016, or later
AIX Version 7.1 with the 7100-05 Technology Level and Service Pack 7100-05-06-2016, or later

IBM Red Hat Enterprise Linux 9.0, for Power LE, or later
IBM Red Hat Enterprise Linux 8.4, for Power LE, or later
SUSE Linux Enterprise Server 15 Service Pack 3, or later
SUSE Linux Enterprise Server for SAP with SUSE Linux Enterprise Server 15 Service Pack 3, or later
Red Hat Enterprise Linux for SAP with Red Hat Enterprise Linux 8.4 for Power LE, or later
Red Hat OpenShift Container Platform 4.9, or later

VIOS 3.1.3.21

19-inch rack-mount hardware Physical Specifications:
Width: 18.97 inches
Depth: 28 inches
Height: 6.8 inches (4U)
Weight: 80 lbs

Tower hardware Physical Specifications:
Width with stand: 13 inches
Depth with front-rotatable door: 32 inches
Height with handle: 20.6 inches
Weight: 105 lbs
