8286-42A IBM Power8 S824 Memory Main Storage Upgrades

8286-42A IBM Power8 Memory S824
IBM POWER8 Memory for 8286-42A

The 8286-42A server supports up to 4TB of IBM POWER8 memory features in 16 CDIMM slots for two socket processor DCM systems, or 1TB maximum memory for single socket processor systems. IBM POWER8 memory for all 8286-42A system models must be installed in identical pairs, but can be of different sizes from other memory pairs. The IBM 4794 Power Active Memory Expansion Enablement feature enables memory expansion on the 8286-42A system, providing compression and decompression of data in memory which expands the maximum memory capacity for additional processing capacity and better performance. IBM POWER8 Memory uses both buffered DDR3 or DDR4 DIMMs, which have the same 1600 MHz speed, use the same L4 cache and the same memory controller. All IBM POWER8 memory is in used or refurbished condition, includes warranty, free technical support by phone or email and is guaranteed for IBM maintenance contracts.

The IBM POWER8 8286-41A S824 systems support the following memory features:

EM91 16GB DDR4 MEMORY 31EC 00VK252
EM92 32GB DDR4 MEMORY 31ED 00VK296

EM93 64GB DDR4 MEMORY 31EE 00VK306
EM94 128GB DDR4 MEMORY 31EF 00VK351
EM95 256GB DDR4 MEMORY 31FC 00VK243
EM8B 16GB DDR3 MEMORY 31E8 00VK193
EM8C 32GB DDR3 MEMORY 31E9 00VK195
EM8D 64GB DDR3 MEMORY 31EA 00VK197
EM8E 128GB DDR3 MEMORY 31EB 00VK198

IBM POWER8 Memory features require firmware 860 or later, and supported on IBM i V7R1 TR8 and higher, AIX 6.1 and higher, Red Hat Enterprise Linux and SUSE Linux Enterprise Server.
