8286-41A IBM Power8 Memory Upgrades S814

IBM POWER8 8286-41A S814 systems support up to 1TB of memory on EPX0 6-core and EPX6 8-core systems, whereas the 4-core EPXK processor system has a maximum of 64GB of memory. The IBM S814 8286-41A POWER8 system models has 16 slots for memory DIMMs. IBM POWER8 Memory uses both buffered DDR3 or DDR4 DIMMs, featuring IBM's Centaur chip embedded directly onto the memory DIMM. IBM DDR4 and DDR3 memory features are the same 1600 MHz speed, use the same L4 cache and the same memory controller. All IBM POWER8 memory is in used or refurbished condition, includes warranty, free technical support by phone or email and is guaranteed for IBM maintenance contracts.

The IBM POWER8 S814 8286-41A systems support the following memory features:

EM91 16GB DDR4 MEMORY 31EC 00VK252
EM92 32GB DDR4 MEMORY 31ED 00VK296
EM93 64GB DDR4 MEMORY 31EE 00VK306
EM94 128GB DDR4 MEMORY 31EF 00VK351

EM8B 16GB DDR3 MEMORY 31E8 00VK193
EM8C 32GB DDR3 MEMORY 31E9 00VK195
EM8D 64GB DDR3 MEMORY 31EA 00VK197
EM8E 128GB DDR3 MEMORY 31EB 00VK198

Memory features must be added in identical pairs with firmware 860 or later. All Power8 S814 8286-41A main storage features are supported on IBM i V7R1 TR8 and higher, AIX 6.1 and higher, Red Hat Enterprise Linux and SUSE Linux Enterprise Server.
