IBM 31EA 64GB DDR3 Power8 Memory 00VK197 EM8D
Brand:
IBM AS400 iSeries
Model Number:
31EA-00VK197-EM8D
Custom Field 1 (UPC):
31EA
Custom Field 4 (MPN): 00VK197
Custom Field 4 (MPN): 00VK197
IBM 31EA 64GB DDR3 Power8 Memory 00VK197 EM8D 8286-41A 8286-42A 8247-42L
The IBM 31EA 64GB DDR3 Memory DIMM has 00VK197 part number, EM8D CCIN and is supported in 8286-41A, 8286-42A and 8247-42L Power8 servers. The maximum quantity of IBM 31EA 64GB memory features that can be installed depends on the specific Power8 Server and number of processor sockets (DCMs). The 8286-42A IBM Power8 S824 server and 8247-42L S824L models with 2 processor sockets can have up to 4TB of memory using 32 memory DIMM slots, or 1TB of IBM memory for single socket systems. The 8286-41A S814 and 8284-22A S822 Power8 Server models supports up to 1TB of memory using 8 Memory DIMM slots. The 8247-21L S812L Power8 Server model supports up to 512GB using 8 memory slots. View the IBM Power8 Server models pages for other memory specifications. IBM Power8 DDR4 memory and DDR3 memory features deliver the same peformance, have the same 1600 MHz speed, L4 cache and use the same memory controller.
IBM Power8 memory features include:
EM8B 16 GB DDR3 MEMORY 31E8 00VK193
EM8C 32 GB DDR3 MEMORY 31E9 00VK195
EM8D 64 GB DDR3 MEMORY 31EA 00VK197
EM8E 128GB DDR3 MEMORY 31EB 00VK198
EM91 16 GB DDR4 MEMORY 31EC 00VK252
EM92 32 GB DDR4 MEMORY 31ED 00VK296
EM93 64 GB DDR4 MEMORY 31EE 00VK306
EM94 128 GB DDR4 MEMORY 31EF 00VK351
EM95 256 GB DDR4 MEMORY 31FC 00VK243
EM96 16GB DDR4 MEMORY 31EC 00VK248
EM97 32GB DDR4 MEMORY 31ED 00VK296
EM98 64GB DDR4 MEMORY 31EE 00VK301
EM8S 128GB DDR4 MEMORY 31EF 00VK273
IBM EM8D 31EA 00VK197 Memory Power8 Server OS Requirements:
IBM i V7R2 with machine code RS720-00 OS & RS720-B LIC, Fix Level C4101720 + HIPER Group
IBM i V7R1 with machine code RS710-00 OS & RS710-B LIC or Technology Refresh 1 PTF Group SF99707, Fix Level C0229710
AIX Version 7.1 7100-03 SP3, Fix Level IV56367 or later
PowerVM Virtual I/O Server VIOS 2.2.3.3
Linux Servers
IBM Red Hat Enterprise Linux RHEL 6.5
SUSE Linux Enterprisee server level SLES 11 SP3
Server Firmware 810.00, Fix Level SV810_054_054
HMC Firmware V8R8.1.0, Fix Level MH01421
IBM i V7R1 with machine code RS710-00 OS & RS710-B LIC or Technology Refresh 1 PTF Group SF99707, Fix Level C0229710
AIX Version 7.1 7100-03 SP3, Fix Level IV56367 or later
PowerVM Virtual I/O Server VIOS 2.2.3.3
Linux Servers
IBM Red Hat Enterprise Linux RHEL 6.5
SUSE Linux Enterprisee server level SLES 11 SP3
Server Firmware 810.00, Fix Level SV810_054_054
HMC Firmware V8R8.1.0, Fix Level MH01421
