IBM S814 8286-41A-EPX0 Power8 6-Core AIX Server
IBM Power8 IBM S814 8286-41A-EPX6 Power8 AIX 8-Core System  .. Product #: 8286-41A-EPX6-S814-AIX

IBM S814 8286-41A-EPX6 Power8 8-Core Processor AIX Server

Brand: IBM Power8
Model Number: 8286-41A-EPX6-S814-AIX
Tags: 8286-41A , S814 , epx6 , Power8 , aix

The IBM 8286-41A-EPX6 model S812 is a 8-core Power8 AIX server optimized for intensive database and high transaction environments with highly multi-threaded applications. These IBM Power8 S812 8286-41A systems deliver up to 2x faster response times for 2x the number of simultaneous threads per processor core and are ideal for consolidating UNIX, Linux and iSeries workloads at a very low price. The 8286-41A2 EPX6 processor has a 143.9 rPerf rating, support up to 1024 GB of internal Memory, 32.4 TB of Disk space or 1,209 TB with EXP24S 5887 expansion drawers.can have up to 160 logical partitions for AIX, Linux or iSeries workloads. Please use our "Request Price" feature to send us your 8286-41A Power8 S814 System requirements.

8286-41A-EPX6 Main Storage Options:
EM91 - IBM Power8 16 GB Memory CDIMM, 1600 Mbps, 4 Gb DDR4 DRAM
EM92  - IBM Power8 32 GB Memory CDIMM, 1600 Mbps, 4 Gb DDR4 DRAM
EM93  - IBM Power8 64 GB Memory CDIMM, 1600 Mbps, 4 Gb DDR4 DRAM
EM94  - IBM Power8 128 GB Memory CDIMM, 1600 Mbps, 4 Gb DDR4 DRAM

8286-41A-EPX6 Specifications and Comparisons

IBM Power8 8-Core 3.72 GHz 64-bit Processor: 143.9 rPerf
L2 Cache per Processor Core: 512 KB
L3 Cache per Processor Core: 8 MB
L4 Cache per Processor Core: Up to 128 MB
EnergyScale: Yes
Chipkill memory: Yes
Service Processor: Yes
Hot-Swappable Disk: Yes
Dynamic Processor Deallocation: Yes
Processor Instruction Retry: Yes
Alternate Processor Recover: Yes
Hot-plug concurrent maintenance PCIe slots: Yes
Redundant hot-plug power: Yes
Redundant hot-plug cooling: Yes
Dual VIOS: Optional
PowerVM Standard Edition: Optional
PowerVM Enterprise Edition: Optional
Max logical partitions: 160
System unit PCIe Gen3 full high slots: 5 PCIe x8 & 2 PCIe x16
Max PCIe Gen3 I/O Drawer: 1
Max PCIe Gen 3 slots in System unit: 5
Max PCIe Gen 3 slots in PCIe I/O drawers: 12
Slimline DVD bay: 1
System unit Disk/SSD bays:
   4-core = 10 SFF (no EXP24S) provide 3TB with 10X300GB Drives
   6 & 8-core = 12 SFF-3 plus optional EXP24S expansion units for 24 SFF-2 bays provide 32.4TB with 18X1.8TB Drives
EXP24S Expansion Drawers: 28 for a total of 672 SFF-2 SAS bays (6 & 8-core only)
Operating Sytems Supported:  AIX, iSeries and Linux on Power



8286-41A SSD and Disk Drive Options:

ES0C - IBM 387GB SFF-2 SSD for AIX/Linux with eMLC
ES0G - IBM 775GB SFF-2 SSD for AIX/Linux
ES0L - IBM 387GB SFF-3 SSD for AIX/Linux
ES0N - IBM 775GB SFF-3 SSD for AIX/Linux
ES0Q - IBM 387GB SFF-2 4K SSD for AIX/Linux
ES0S - IBM 775GB SFF-2 4k SSD for AIX/Linux
ES0U - IBM 387GB SFF-3 4k SSD AIX/Linux
ES0W - IBM 775GB SFF-3 4k SSD for AIX/Linux
ES0W - IBM 775GB SFF-3 4k SSD for AIX/Linux
ES19 - IBM 387GB SFF-2 SSD for AIX/Linux
ES62 - IBM 3.86-4.0 TB 7200 RPM 4K SAS LFF-1 Nearline Disk Drive for AIX/Linux
ES64 - IBM 7.72-8.0 TB 7200 RPM 4K SAS LFF-1 Nearline Disk Drive for AIX/Linux
ES78 - IBM 387GB SFF-2 SSD 5xx eMLC4 for AIX/Linux
ES0W - IBM 775GB SFF-3 4k SSD for AIX/Linux
ES7E - IBM 775GB SFF-2 SSD 5xx eMLC4 for AIX/Linux
ES7K - IBM 387GB SFF-3 SSD 5xx eMLC4 for AIX/Linux
ES7P - IBM 775GB SFF-3 SSD 5xx eMLC4 for AIX/Linux
ES80 - IBM 1.9TB Read Intensive SAS 4k SFF-2 SSD for AIX/Linux
ES83 - IBM 931GB Mainstream SAS 4k SFF-3 SSD for AIX/Linux
ES85 - IBM 387GB SFF-2 SSD 4k eMLC4 for AIX/Linux
ES8C - IBM 775GB SFF-2 SSD 4k eMLC4 for AIX/Linux
ES8F - IBM 1.55TB SFF-2 SSD 4k eMLC4 for AIX/Linux
ES8J - IBM 1.9TB Read Intensive SAS 4k SFF-3 SSD for AIX/Linux
ES8N - IBM 387GB SFF-3 SSD 4k eMLC4 for AIX/Linux
ES8Q - IBM 775GB SFF-3 SSD 4k eMLC4 for AIX/Linux
ES8V - IBM 1.55TB SFF-3 SSD 4k eMLC4 for AIX/Linux
ES8Y - IBM 931GB Mainstream SAS 4k SFF-2 SSD for AIX/Linux
ES92 - IBM 1.86TB Mainstream SAS 4k SFF-3 SSD for AIX/Linux
ES96 - IBM 1.86TB Mainstream SAS 4k SFF-2 SSD for AIX/Linux
ESD3 - IBM 1.2TB 10K RPM SAS SFF-2 Disk Drive for AIX/Linux
ESD5 - IBM 600GB 10K RPM SAS SFF-3 Disk Drive for AIX/Linux
ESD9 - IBM 1.2TB 10K RPM SAS SFF-3 Disk Drive for AIX/Linux
ESDB - IBM 300GB 15K RPM SAS SFF-3 Disk Drive for AIX/Linux
ESDR - IBM 300GB 10k RPM SAS SFF-3 Disk Drive for AIX/Linux
ESDT - IBM 146GB 15k RPM SAS SFF-3 Disk Drive for AIX/Linux
ESE1 - IBM 3.72TB Mainstream SAS 4k SFF-3 SSD for AIX/Linux
ESE7 - IBM 3.72TB Mainstream SAS 4k SFF-2 SSD for AIX/Linux
ESG5 - IBM 387GB Enterprise SAS 5xx SFF-2 SSD for AIX/Linux
ESG9 - IBM 387GB Enterprise SAS 5xx SFF-3 SSD for AIX/Linux
ESGB - IBM 387GB Enterprise SAS 4k SFF-2 SSD for AIX/Linux
ESGD - IBM 387GB Enterprise SAS 4k SFF-3 SSD for AIX/Linux
ESGF - IBM 775GB Enterprise SAS 5xx SFF-2 SSD for AIX/Linux
ESGH - IBM 775GB Enterprise SAS 5xx SFF-3 SSD for AIX/Linux
ESGK - IBM 775GB Enterprise SAS 4k SFF-2 SSD for AIX/Linux
ESGM - IBM 775GB Enterprise SAS 4k SFF-3 SSD for AIX/Linux
ESGP - IBM 1.55TB Enterprise SAS 4k SFF-2 SSD for AIX/Linux
ESHJ - IBM 931 GB Mainstream SAS 4k SFF-2 SSD for AIX/Linux
ESGR - IBM 1.55TB Enterprise SAS 4k SFF-3 SSD for AIX/Linux
ESHL - IBM 1.86 TB Mainstream SAS 4k SFF-2 SSD for AIX/Linux
ESHS - IBM 931 GB Mainstream SAS 4k SFF-3 SSD for AIX/Linux
ESHU - IBM 1.86 TB Mainstream SAS 4k SFF-3 SSD for AIX/Linux
ESM8 - IBM 3.72 TB Mainstream SAS 4k SFF-2 SSD for AIX/Linux
ESMQ - IBM 3.72 TB Mainstream SAS 4k SFF-3 SSD for AIX/Linux
ESNK - IBM 300GB 15K RPM SAS SFF-3 4k Block Cached Disk Drive for AIX/Linux
ESNM - IBM 300GB 15K RPM SAS SFF-2 4k Block Cached Disk Drive for AIX/Linux
ESNP - IBM 600GB 15K RPM SAS SFF-3 4k Block Cached Disk Drive for AIX/Linux
ESNR - IBM 600GB 15K RPM SAS SFF-2 4k Block Cached Disk Drive for AIX/Linux
ES0D - IBM i 387GB SFF-2 SSD for iSeries with eMLC
ES0H - IBM i 775GB SFF-2 SSD for iSeries
ES0M - IBM i 387GB SFF-3 SSD for iSeries
ES0P - IBM i 775GB SFF-3 SSD for iSeries
ES0R - IBM i 387GB SFF-2 4k SSD for iSeries
ES0T - IBM i 775GB SFF-2 4k SSD for iSeries
ES0V - IBM i 387GB SSF-3 4k SSD for iSeries
ES0X - IBM i 775GB SFF-3 4k SSD for iSeries
ES1A - IBM i 387GB SFF-2 SSD for iSeries
ES79 - IBM i 387GB SFF-2 SSD 5xx eMLC4 for iSeries
ES7F - IBM i 775GB SFF-2 SSD 5xx eMLC4 for iSeries
ES7L - IBM i 387GB SFF-3 SSD 5xx eMLC4 for iSeries
ES7Q - IBM i 775GB SFF-3 SSD 5xx eMLC4 for iSeries
ES81 - IBM i 1.9TB Read Intensive SAS 4k SFF-2 SSD for iSeries
ES84 - IBM i 931GB Mainstream SAS 4k SFF-3 SSD for iSeries
ES86 - IBM i 387GB SFF-2 SSD 4k eMLC4 for iSeries
ES8D - IBM i 775GB SFF-2 SSD 4k eMLC4 for iSeries
ES8G - IBM i 1.55TB SFF-2 SSD 4k eMLC4 for iSeries
ES8K - IBM i 1.9TB Read Intensive SAS 4k SFF-3 SSD for iSeries
ES8P - IBM i 387GB SFF-3 SSD 4k eMLC4 for iSeries
ES8R - IBM i 775GB SFF-3 SSD 4k eMLC4 for iSeries
ES8W - IBM i 1.55TB SFF-3 SSD 4k eMLC4 for iSeries
ES8Z - IBM i 931GB Mainstream SAS 4k SFF-2 SSD for iSeries
ES93 - IBM i 1.86TB Mainstream SAS 4k SFF-3 SSD for iSeries
ES97 - IBM i 1.86TB Mainstream SAS 4k SFF-2 SSD for iSeries
ESD2 - IBM i 1.1TB 10K RPM SAS SFF-2 Disk Drive (IBMi)
ESD4 - IBM i 571GB 10K RPM SAS SFF-3 Disk Drive iSeries
ESD8 - IBM i 1.1TB 10K RPM SAS SFF-3 DIsk Drive iSeries
ESDA - IBM i 283GB 15K RPM SAS SFF-3 Disk Drive iSeries
ESDE - IBM i 571GB 15k RPM SAS SFF-3 Disk Drive
ESDF - IBM i 600GB 15k RPM SAS SFF-3 Disk Drive
ESDN - IBM i 571GB 15K RPM SAS SFF-2 Disk Drive
ESDP - IBM i 600GB 15K RPM SAS SFF-2 Disk Drive
ESDS - IBM i 283GB 10k RPM SAS SFF-3 Disk Drive iSeries
ESDU - IBM i 139GB 15k RPM SAS SFF-3 Disk Drive iSeries
ESDV - IBM i 283GB 15K RPM SAS SFF-3 Disk 5xx Block
ESE2 - IBM i 3.72TB Mainstream SAS 4k SFF-3 SSD for iSeries
ESE8 - IBM i 3.72TB Mainstream SAS 4k SFF-2 SSD for iSeries
ESEU - IBM i 571GB 10K RPM SAS SFF-2 Disk Drive 4K Block
ESEV - IBM i 600GB 10K RPM SAS SFF-2 Disk Drive 4K Block
ESEY - IBM i 283GB 15K RPM SAS SFF-2 4K Block
ESEZ - IBM i 300GB 15K RPM SAS SFF-2 4K Block
ESF2 - IBM i 1.1TB 10K RPM SAS SFF-2 Disk Drive 4K Block
ESF3 - IBM i 1.2TB 10K RPM SAS SFF-2 Disk Drive 4K Block
ESF4 - IBM i 571GB 10K RPM SAS SFF-3 Disk Drive 4K Block
ESF5 - IBM i 600GB 10K RPM SAS SFF-3 Disk Drive 4K Block
ESF8 - IBM i 1.1TB 10K RPM SAS SFF-3 Disk Drive 4K Block
ESF9 - IBM i 1.2TB 10K RPM SAS SFF-3 Disk Drive 4K Block
ESFA - IBM i 283GB 15K RPM SAS SFF-3 4K Block
ESFB - IBM i 300GB 15K RPM SAS SFF-3 4K Block
ESFE - IBM i 571GB 15K RPM SAS SFF-3 4K Block
ESFF - IBM i 600GB 15K RPM SAS SFF-3 4K Block
ESFG - IBM i 283GB 15K RPM SAS SFF-3 Disk 4K Block
ESFN - IBM i 571GB 15K RPM SAS SFF-2 4K Block
ESFP - IBM i 600GB 15K RPM SAS SFF-2 4K Block
ESFS - IBM i 1.7TB 10K RPM SAS SFF-2 Disk Drive 4K Block
ESFT - IBM i 1.8TB 10K RPM SAS SFF-2 Disk Drive 4K Block
ESFU - IBM i 1.7TB 10K RPM SAS SFF-3 Disk Drive 4K Block
ESFV - IBM i 1.8TB 10K RPM SAS SFF-3 Disk Drive 4K Block
ESG6 - IBM i 387GB Enterprise SAS 5xx SFF-2 SSD for iSeries
ESGA - IBM i 387GB Enterprise SAS 5xx SFF-3 SSD for iSeries
ESGC - IBM i 387GB Enterprise SAS 4k SFF-2 SSD for iSeries
ESGE - IBM i 387GB Enterprise SAS 4k SFF-3 SSD for iSeries
ESGG - IBM i 775GB Enterprise SAS 5xx SFF-2 SSD for iSeries
ESGJ - IBM i 775GB Enterprise SAS 5xx SFF-3 SSD for iSeries
ESGL - IBM i 775GB Enterprise SAS 4k SFF-2 SSD for iSeries
ESGN - IBM i 775GB Enterprise SAS 4k SFF-3 SSD for iSeries
ESGQ - IBM i 1.55TB Enterprise SAS 4k SFF-2 SSD for iSeries
ESGS - IBM i 1.55TB Enterprise SAS 4k SFF-3 SSD for iSeries
ESHK - IBM i 931 GB Mainstream SAS 4k SFF-2 SSD for iSeries
ESHM - IBM i 1.86 TB Mainstream SAS 4k SFF-2 SSD for iSeries
ESHT - IBM i 931 GB Mainstream SAS 4k SFF-3 SSD for iSeries
ESHV - IBM i 1.86 TB Mainstream SAS 4k SFF-3 SSD for iSeries
ESM9 - IBM i 3.72 TB Mainstream SAS 4k SFF-2 SSD for iSeries
ESMR - IBM i 3.72 TB Mainstream SAS 4k SFF-3 SSD for iSeries
ESNJ - IBM i 283GB 15K RPM SAS SFF-3 4k Block Cached Disk Drive iSeries
ESNL - IBM i 283GB 15K RPM SAS SFF-2 4k Block Cached Disk Drive iSeries
ESNN - IBM i 571GB 15K RPM SAS SFF-3 4k Block Cached Disk Drive iSeries
ESNQ - IBM i 571GB 15K RPM SAS SFF-2 4k Block Cached Disk Drive iSeries
