00GH761 IBM AGKF LTO6 Fiber Channel Half High Tape Drive
00GH761 is the part number for an IBM AGKF LTO6 single port Fibre Channel Half-High Tape Drive that can be installed in an IBM TS4300Tape Library Model 3555, and has a maximum native data transfer rate of 160 MB per second. The 00GH761 IBM AGKF LTO6 Fibre Channel Tape Drive cables are not included and must be ordered separately and are required to attach the TS4300 Tape Library to a host Fibre Channel adapter. The IBM LTO6 Tape Drive is a high-performance, high-capacity tape storage backup and restore device for IBM i, AIX, Linux Power Servers and other open system platforms. IBM Ultrium 6 or LTO6 tape cartridge can store up to 2.5 TB of uncompressed data or up to 6.25 TB of compressed data assuming a 2.5 to 1 compression ratio.
IBM LTO Tape Drive Options for IBM TS4300 3555-L3A LTO Tape Library 00VJ943
or
Three HH Drives (AGKF AGKG AGKJ AGKK AGKM AGKN) in any combination in a Model L3A and E3A
One FH Drive (AGKH AGKL AGKP) and One HH Drives (AGKF AGKG AGKJ AGKK AGKM AGKN)
or
Three HH Drives (AGKF AGKG AGKJ AGKK AGKM AGKN) in any combination in a Model L3A and E3A
One FH Drive (AGKH AGKL AGKP) and One HH Drives (AGKF, AGKG, AGKJ, AGKK, AGKM, AGKN)
or
Three HH Drives (AGKF AGKG AGKJ AGKK AGKM AGKN) in any combination in a Model L3A and E3A
One FH Drive (AGKH AGKL AGKP) and One HH Drives (AGKF AGKG AGKJ AGKK AGKM AGKN)
or
Three HH Drives (AGKF AGKG AGKJ AGKK AGKM AGKN) in any combination in a Model L3A and E3A
One FH Drive (AGKH AGKL) and One HH Drives (AGKF AGKG AGKJ AGKK)
or
Three HH Drives (AGKF AGKG AGKJ AGKK) in any combination in a Model L3A and E3A
One FH Drive (AGKH AGKL) and One HH Drives (AGKF AGKG AGKJ AGKK)
or
Three HH Drives (AGKF AGKG AGKJ AGKK) in any combination in a Model L3A and E3A.
One FH Drive (AGKH AGKL AGKP) and One HH Drives (AGKF AGKG AGKJ AGKK AGKM AGKN)
or
Three HH Drives (AGKF AGKG AGKJ AGKK AGKM AGKN) in any combination in a Model L3A and E3A
Other IBM LTO6 tape drives supported in the IBM TS4300 Tape Library Model 3555 include: IBM AGKH 00GH763 LTO6 Dual-Port Fibre Channel Full-High Tape Drive, IBM AGKF 00GH761 LTO6 Fibre Channel Half-High Tape Drive, and the IBM AGKG 00GH759 LTO6 SAS Tape Drive Half-High. All IBM LTO6 Tape Drives have a 160 MB per second maximum native transfer rate.
Note: The actual capacity varies depending on the application, the type of data, and the tape cartridge. 2.5 TB is typical and 6.25 TB is possible when the Data Compression setting is activated. LTO data transfer rates are also greatly improved when using compression. The default setting of Data Compression is controlled by the host system. The user and the application software can control the activation or deactivation of the data compression setting. The drive can typically achieve a 2.5:1 compression ratio.
| LTO Ultrium Tape Media Cartridge | ||||||||
|
Generation |
LTO9 | LTO8 | LTO7 | LTO6 | LTO5 | LTO4 | LTO3 | LTO2 |
| LTO9 | R/W |
R/W | ||||||
| LTO8 | R/W | R/W | ||||||
| LTO7 | R/W | R/W | R | |||||
| LTO6 | R/W | R/W | R | |||||
| LTO5 | R/W | R/W | R | |||||
| LTO4 | R/W | R/W | R | |||||
| LTO3 | R/W | R/W | ||||||
| LTO2 | R/W | |||||||
IBM LTO Tape Drive Options for IBM TS4300 3555-L3A LTO Tape Library 00VJ943
or
Three HH Drives (AGKF, AGKG, AGKJ, AGKK, AGKM, AGKN) in any combination in a Model L3A and E3A
One FH Drive (AGKH, AGKL, AGKP), and One HH Drives (AGKF, AGKG, AGKJ, AGKK, AGKM, AGKN)
or
Three HH Drives (AGKF, AGKG, AGKJ, AGKK, AGKM, AGKN) in any combination in a Model L3A and E3A
One FH Drive (AGKH, AGKL, AGKP), and One HH Drives (AGKF, AGKG, AGKJ, AGKK, AGKM, AGKN)
or
Three HH Drives (AGKF, AGKG, AGKJ, AGKK, AGKM, AGKN) in any combination in a Model L3A and E3A
One FH Drive (AGKH, AGKL, AGKP), and One HH Drives (AGKF, AGKG, AGKJ, AGKK, AGKM, AGKN)
or
Three HH Drives (AGKF, AGKG, AGKJ, AGKK, AGKM, AGKN) in any combination in a Model L3A and E3A
One FH Drive (AGKH, AGKL), and One HH Drives (AGKF, AGKG, AGKJ, AGKK)
or
Three HH Drives (AGKF, AGKG, AGKJ, AGKK) in any combination in a Model L3A and E3A
One FH Drive (AGKH, AGKL), and One HH Drives (AGKF, AGKG, AGKJ, AGKK)
or
Three HH Drives (AGKF, AGKG, AGKJ, AGKK) in any combination in a Model L3A and E3A.
One FH Drive (AGKH, AGKL, AGKP), and One HH Drives (AGKF, AGKG, AGKJ, AGKK, AGKM, AGKN)
or
Three HH Drives (AGKF, AGKG, AGKJ, AGKK, AGKM, AGKN) in any combination in a Model L3A and E3A
One FH Drive (AGKH, AGKL), and One HH Drives (AGKF, AGKG, AGKJ, AGKK)
or
Three HH Drives (AGKF, AGKG, AGKJ, AGKK) in any combination in a Model L3A and E3A
One FH Drive (AGKH, AGKL), and One HH Drives (AGKF, AGKG, AGKJ, AGKK)
or
Three HH Drives (AGKF, AGKG, AGKJ, AGKK) in any combination in a Model L3A and E3A
LTO8: 300 MB/sec native Half-High | 30 TB with 2.5:1 compression
LTO7 Type M: 300 MB/sec native | 22.5 TB with 2.5:1 compression
LTO7: 300 MB/sec native | 15 TB with 2.5:1 compression
LTO6: 160 MB/sec native | 6.25 TB with 2.5:1 compression
ASG Time Navigator
Barracuda Yosemite Backup
CommVault Simpana
Dell NetVault Backup
EMC NetWorker
HP OpenView Storage Data Protector
IBM Spectrum Protect
Microsoft System Center Data Protection Manager
Symantec Backup Exec
Symantec NetBackup
The IBM TS4300 Tape Library is supported on the following operating systems at the minimum levels indicated:
IBM i iSeries AS400
IBM BladeCenter
IBM Flex System
IBM Power Systems (p6 or later)
IBM System p (p5 or older)
IBM System z and S/390
Advanced Micro Devices (AMD)
Hewlett Packard
Intel (x86 and x86_64)
Sun
