00GH766 IBM AGKJ LTO7 Fiber Channel Tape Drive Half-High
00GH766 is the part number for an IBM AGKJ LTO7 Fiber Channel Half-High Tape Drive that has a single 8Gb interface port, has a maximum data transfer rate of 800 MB per second and can be installed in an IBM TS4300 Tape Library Model 3555. The IBM AGKJ LTO7 Fiber Channel Tape Drive Half-High Cables are not included and must be ordered separately and are required to attach the TS4300 IBM LTO Tape Library to a host Fiber Channel adapter.
The IBM LTO7 Tape Drive is a high-performance, high-capacity tape storage backup and restore device for IBM i, AIX, Linux Power Servers and other open system platforms. IBM Ultrium 7 or LTO7 tape cartridge can store up to 6 TB of uncompressed data or up to 15 TB of compressed data assuming a 2.5 to 1 compression ratio.
IBM LTO7 half-high tape drives can connect with a 8Gb Fiber Channel interface and have a maximum 800 MB per second transfer rate and will auto-negotiate to lower speeds. The IBM AGKJ LTO7 Fibre Channel Half-High Tape Drive with 00GH766 part number can also be purchased in a full height format as IBM AGKL LTO7 Fiber Channel Full-High Tape Drive with 00GH768 part number and also has a 800 MB per second maximum transfer rate. The IBM AGKK LTO7 SAS Tape Drive Half-High with part number 00GH764 has a 600 MB per second maximum transfer rate.
Note: The actual capacity varies depending on the application, the type of data, and the tape cartridge. 6 TB is typical and 15 TB is possible when the Data Compression setting is activated. The default setting of Data Compression is controlled by the host system. The user and the application software can control the activation or deactivation of the data compression setting. The drive can typically achieve a 2.5:1 compression ratio.
IBM LTO Tape Drive Options for IBM TS4300 3555-L3A LTO Tape Library 00VJ943
or
Three HH Drives (AGKF AGKG AGKJ AGKK AGKM AGKN) in any combination in a Model L3A and E3A
One FH Drive (AGKH AGKL AGKP) and One HH Drives (AGKF AGKG AGKJ AGKK AGKM AGKN)
or
Three HH Drives (AGKF AGKG AGKJ AGKK AGKM AGKN) in any combination in a Model L3A and E3A
One FH Drive (AGKH AGKL AGKP) and One HH Drives (AGKF, AGKG, AGKJ, AGKK, AGKM, AGKN)
or
Three HH Drives (AGKF AGKG AGKJ AGKK AGKM AGKN) in any combination in a Model L3A and E3A
One FH Drive (AGKH AGKL AGKP) and One HH Drives (AGKF AGKG AGKJ AGKK AGKM AGKN)
or
Three HH Drives (AGKF AGKG AGKJ AGKK AGKM AGKN) in any combination in a Model L3A and E3A
One FH Drive (AGKH AGKL) and One HH Drives (AGKF AGKG AGKJ AGKK)
or
Three HH Drives (AGKF AGKG AGKJ AGKK) in any combination in a Model L3A and E3A
One FH Drive (AGKH AGKL) and One HH Drives (AGKF AGKG AGKJ AGKK)
or
Three HH Drives (AGKF AGKG AGKJ AGKK) in any combination in a Model L3A and E3A.
One FH Drive (AGKH AGKL AGKP) and One HH Drives (AGKF AGKG AGKJ AGKK AGKM AGKN)
or
Three HH Drives (AGKF AGKG AGKJ AGKK AGKM AGKN) in any combination in a Model L3A and E3A
| LTO Ultrium Tape Media Cartridge | ||||||||
|
Generation |
LTO9 | LTO8 | LTO7 | LTO6 | LTO5 | LTO4 | LTO3 | LTO2 |
| LTO9 | R/W |
R/W | ||||||
| LTO8 | R/W | R/W | ||||||
| LTO7 | R/W | R/W | R | |||||
| LTO6 | R/W | R/W | R | |||||
| LTO5 | R/W | R/W | R | |||||
| LTO4 | R/W | R/W | R | |||||
| LTO3 | R/W | R/W | ||||||
| LTO2 | R/W | |||||||
LTO8: 300 MB/sec native Half-High | 30 TB with 2.5:1 compression
LTO7 Type M: 300 MB/sec native | 22.5 TB with 2.5:1 compression
LTO7: 300 MB/sec native | 15 TB with 2.5:1 compression
LTO6: 160 MB/sec native | 6.25 TB with 2.5:1 compression
ASG Time Navigator
Barracuda Yosemite Backup
CommVault Simpana
Dell NetVault Backup
EMC NetWorker
HP OpenView Storage Data Protector
IBM Spectrum Protect
Microsoft System Center Data Protection Manager
Symantec Backup Exec
Symantec NetBackup
The IBM TS4300 Tape Library is supported on the following operating systems at the minimum levels indicated:
IBM i iSeries AS400
IBM BladeCenter
IBM Flex System
IBM Power Systems (p6 or later)
IBM System p (p5 or older)
IBM System z and S/390
Advanced Micro Devices (AMD)
Hewlett Packard
Intel (x86 and x86_64)
Sun
