IBM Power9 Systems Power9 L922 9008-22L ELPW 20-core Linux Server  .. Product #: 9008-22L-ELPW-20core

Power9 9008-22L ELPW 20-core L922 Linux Server

Brand: IBM Power9 Systems
Model Number: 9008-22L-ELPW-20core
Tags: linux server , power9 , 9008-22l , ibm l922

The IBM Power9 9008-22L ELPW is a 20-core Linux Server with 2 processor sockets that delivers 2.9 GHz to 3.8 GHz, and can have up to 20 ELAW Processor Core Activations. Power9 9008-22L L922 Linux servers can have up to 2 Processor sockets, 8-24 Cores, 4TB RAM for 340 GB/s memory bandwidth, up to 14.4 TB internal storage and 672 drives of external storage for 1,209 TB, 480 partitions, use Gen4 NVLink 2.0 and 2nd gen OpenCapi to provide 5.6x more CPU-GPU bandwidth I/O throughput than x86 servers, provide 4x more threads per core than x86 servers, 512 K L2 cache and 10 MB L3 cache for a maximum of 7 TB/s on chip bandwidth. Power9 Linux servers provide better performance per core, requiring less cores to run applications and databases, which can drastically reduce software license costs and all other operating costs. The Power99008-22L L922 is considered one of the best Linux servers that support Ubuntu, IBM RedHat and SuSE.

Specifications 9008-22L ELPW 20-core Power9 Linux Server

Up to Two Power9 processor socket modules:
9008-ELPW 20-core 2.9-3.8 GHz POWER9 Processor (2 socket)
L2 Cache per core: 512 K
L3 Cache per core: 10 MB
L2 to L3 cache bandwidth: 7 TB/s on chip bandwidth

Other 9008-22L Power9 Server Processor Models
9008-ELPV 8-core 3.4-3.9 GHz POWER9 Processor
9008-ELPW 10-core 2.9-3.8 GHz POWER9 Processor
9008-ELPX 12-core 2.7-3.8 GHz POWER9 Processor
9008-ELPV 16-core 3.4-3.9 GHz POWER9 Processor (2 socket)
9008-ELPX 24-core 2.7-3.8 GHz POWER9 Processor (2 socket)


RAM: 32 DDR4 ECC Power9 MemoryDIMM slots, 4TB is maximum (2TB per Processor socket)
324E EM62 78P4197 - 16 GB DDR4 Memory
324F EM63 78P4198 - 32 GB DDR4 Memory
325A EM64 78P4199 - 64 GB DDR4 Memory
324C EM65 78P4200 - 128 GB DDR4 Memory
Note: 340 GB/s memory bandwidth per system (170 GB/s per processor socket). Memory runs at different frequencies of 2133, 2400, and 2666 Mbps depending on sizes and configuration.

Storage Options:
Supports up to 14.4 TB internal storage for SSD or hard disk drives and 672 drives of external storage for 1,209 TB
8 SFF-3 bays, one integrated SAS controller without cache, and JBOD RAID 0, 5, 6, or 10
Optionally, split the above SFF-3 bays and add a second integrated SAS controller without cache.
Expanded Function Storage Backplane 8 SFF-3 Bays/Single IOA with Write Cache.
Optionally, attach an EXP12SX/EXP24SX SAS HDD/SSD Expansion Drawer to the single IOA.
Note: Up to two PCIe3 NVMe carrier cards with two M.2 module slots (with up to four mainstream 400 GB SSD NVMe M.2 modules)
A quantity of one PCIe3 NVMe carrier card can be ordered only with a storage backplane. If a PCIe3 NVMe carrier card is ordered with a storage backplane, then the optional split feature is not supported.

PCIe adapter slots for two processor socket:
Three x16 Gen4 low-profile, half-length (CAPI)
Two x8 Gen4 low-profile, half-length (with x16 connectors) (CAPI)
Two x8 Gen3 low-profile, half-length (with x16 connectors)
Two x8 Gen3 low-profile, half-length (One of these slots is used for the required base LAN adapter.)

Integrated Standard Adapter Slots:
Service processor with: 25Gb/s per socket, EnergyScale technology, Hot-plug and redundant cooling, Two front USB 3.0 ports, Two rear USB 3.0 ports, Two HMC 1 GbE RJ45 ports, One system port with RJ45 connector, Two hot-plug, redundant power supplies
PowerVM Enterprise Integrated
PowerVM Enterprise delivers industrial-strength virtualization for Linux server and IBM AIX environments on POWER processor-based systems, includes virtualization-oriented performance monitor with performance statistics available on the HMC. These virtualization performance statistics can be used to understand the workload characteristics and help prepare for capacity planning.

Storage options:
For boot from NVMe: One NVMe carrier and one NVMe M.2 Module.
For boot from local SFF-3 HDD/SDD: One storage backplane and one SFF-3 HDD or SDD.
For boot from SAN: Internal HDD or SSD and RAID card are not required if feature 0837 (Boot from SAN) is selected. A Fiber Channel adapter must be ordered if feature 0837 is selected.

Network options:
One PCIe2 4-port 1 Gb Ethernet adapter
One of the supported 10Gb Ethernet adapters
I/O ports for Connectivity: One front USB 3.0 ports, Two rear USB 3.0 ports, Two HMC 1GbE RJ45 ports, One system port with RJ45 connector, 1x USB 3.0 front, 2x USB 3.0 rear, 2x HMC 1 GB Eth RJ45 ports, one system port with RJ45 connector, 2x High Speed 25 Gb/s ports

Operating Systems Supported:
Ubuntu 16.04.4 LTS (P8 Compatibility Mode)
IBM RedHat RHEL 7.4 LE (P8 Compatibility Mode)
SuSE SLES 11 SP4 (P8 Compatibility Mode)
SuSE SLES 12 SP3

Weight and Dimensions:
Width: 482 mm (18.97 in.)
Depth: 766.5 mm (30.2 in.)
Height: 86.7 mm (3.4 in.)
Weight: 30.4 kg (67 lb)
Fits 2U 19-inch, includes rack-mounting hardware

Two EL1B power supplies supporting a rack: 1+1 1400 Watt 200 - 240 Volt

Other Power9 Linux Server Hardware Models and Specifications:
9008-22L S922 1 or 2 Processors, 8-12 Cores, 4TB Memory
9183-22X IC922 1 or 2 Processors, 12-20 Cores, 2TB Memory
9006-12P LC921 1 or 2 Processors, 16-40 Cores, 1TB Memory
9006-22P LC922 1 or 2 Processors, 16-44 Cores, 1TB Memory
8335-GTH AC922 2 Processors, 16-20 Cores, 2TB Memory
8335-GTX AC922 2 Processors, 16-22 Cores, 2TB Memory
9009-41A S914 1 Processor, 4-8 Cores, 1TB Memory
9009-42A S924 1 or 2 Processors, 8-12 Cores, 4TB Memory
9009-22A S922 1 or 2 Processors, 4-10 Cores, 4TB Memory
9040-MR9 E950 2 or 4 Processors, 32-48 Cores, 2 Sockets, 16TB Memory
9040-MR9 E950 2 or 4 Processors, 32-48 Cores, 4 Sockets, 16TB Memory
9080-M9S E980 (1 Node) 32-48 Processors, 4 Sockets, 16TB Memory
9080-M9S E980 (2 Node) 64-96 Processors, 8 Sockets, 16TB Memory
9080-M9S E980 (3 Node) 96-144 Processors, 12 Sockets, 16TB Memory
9080-M9S E980 (4 Node) 128-192 Processors, 16 Sockets, 16TB Memory

Power9 SSD and Hard Disk Drive options

EL78 - 387GB SFF-2 SSD 5xx eMLC4
EL7E - 775GB SFF-2 SSD 5xx eMLC4
EL7K - 387GB SFF-3 SSD 5xx eMLC4
EL7P - 775GB SFF-3 SSD 5xx eMLC4
EL80 - 1.9TB Read Intensive SAS 4k SFF-2 SSD
EL83 - 931GB Mainstream SAS 4k SFF-3 SSD
EL85 - 387GB SFF-2 SSD 4k eMLC4
EL8C - 775GB SFF-2 SSD 4k eMLC4
EL8F - 1.55TB SFF-2 SSD 4k eMLC4
EL8J - 1.9TB Read Intensive SAS 4k SFF-3 SSD
EL8N - 387GB SFF-3 SSD 4k eMLC4
EL8Q - 775GB SFF-3 SSD 4k eMLC4
EL8V - 1.55TB SFF-3 SSD 4k eMLC4
EL8Y - 931GB Mainstream SAS 4k SFF-2 SSD
EL92 - 1.86TB Mainstream SAS 4k SFF-3 SSD
EL96 - 1.86TB Mainstream SAS 4k SFF-2 SSD
ELD5 - 600GB 10K RPM SAS SFF-3 Disk Drive
ELDB - 300GB 15K RPM SAS SFF-3 Disk Drive
ELE1 - 3.72TB Mainstream SAS 4k SFF-3 SSD
ELE7 - 3.72TB Mainstream SAS 4k SFF-2 SSD
ELEV - 600GB 10K RPM SAS SFF-2 Disk Drive 4K Block
ELEZ - 300GB 15K RPM SAS SFF-2 4K Block
ELF3 - 1.2TB 10K RPM SAS SFF-2 Disk Drive 4K Block
ELF5 - 600GB 10K RPM SAS SFF-3 Disk Drive 4K Block
ELF9 - 1.2TB 10K RPM SAS SFF-3 Disk Drive 4K Block
ELFB - 300GB 15K RPM SAS SFF-3 4K Block Disk Drive
ELFF - 600GB 15K RPM SAS SFF-3 4K Block Disk Drive
ELFP - 600GB 15K RPM SAS SFF-2 4K Block Disk Drive
ELFT - 1.8TB 10K RPM SAS SFF-2 Disk Drive 4K Block
ELFV - 1.8TB 10K RPM SAS SFF-3 Disk Drive 4K Block
ELG5 - 387GB Enterprise SAS 5xx SFF-2 SSD
ELG9 - 387GB Enterprise SAS 5xx SFF-3 SSD
ELGB - 387GB Enterprise SAS 4k SFF-2 SSD
ELGD - 387GB Enterprise SAS 4k SFF-3 SSD
ELGF - 775GB Enterprise SAS 5xx SFF-2 SSD
ELGH - 775GB Enterprise SAS 5xx SFF-3 SSD
ELGK - 775GB Enterprise SAS 4k SFF-2 SSD
ELGM - 775GB Enterprise SAS 4k SFF-3 SSD
ELGP - 1.55TB Enterprise SAS 4k SFF-2 SSD
ELGR - 1.55TB Enterprise SAS 4k SFF-3 SSD
ESRL - 300GB 15K RPM SAS SFF-3 4k Block Cached Disk Drive
ESRM - 300GB 15K RPM SAS SFF-2 4k Block Cached Disk Drive
ESRP - 600GB 15K RPM SAS SFF-3 4k Block Cached Disk Drive
ESRR - 600GB 15K RPM SAS SFF-2 4k Block Cached Disk Drive
