IBM 8202-E4C-EPC5 iSeries Power7 4-Core 23800 CPW P05
System Specifications:
CPW Max: 23800, P05 Group, 2 x #EPD5 (chargeable) and 2 x #EPE5 (no-charge)
CPW by Active Processors: 1 = 7300 CPW, 2 = 12800 CPW, 3 = 18300 CPW, 4 = 23800 CPW
Disk Drive/SSD/Tape slots: 8 disk slots in system unit for up to 4.8 TB, and up to 380 TB using HDD or 228 TB using SSD via I/O Drawers.
Memory: 4 GB to 64 GB (1066 MHz DDR3)
L2 Cache: 256 KB per core MB per core
L3 Cache: 4 MB per core
Partitions: 10 dynamic LPARs per processor using PowerVM Standard Edition (#5227) or Enterprise Edition (#5228) feature
PCI Slots: 5 PCIe 8x full high in system unit
Send us your 8202-E4C-EPC5 requirements and we send you a quote based on your specifications. If MES Upgrade, provide Model and Serial Number of current system. Other 8202-E4C processors and systems:
8202-E4C 6-core EPC6 3.0 GHz Processor, 34900 CPW Max, P10 Group
8202-E4C 8-core EPC7 3.0 GHz Processor, 46300 CPW Max, P10 Group
8202-E4C-EPC5 Model 720 Data Sheet IBM Power 7 Features & Facts
View IBM Power9, Power8, Power6 or Power5 system models here.
Other features of the IBM Power7 720 8202-E4C-EPC5 4-Core server include:
- Up to 9 PCIe Gen2 expansion slots 5 PCIe Gen2 x8 expansion slots
- 4 additional PCIe Gen2 x8 low-profile slots (optional) Note: PCIe Gen2 slots can transfer data at double the speed. The high data transfer rates offered by the PCIe Gen2 slots can allow higher I/O performance or consolidation of the I/O demands onto fewer adapters at higher speeds.
- 1 GX++ slot for 12X I/O loop (6-core and 8-core only)
- Either the 2-port 10/100/1000 Ethernet Adapter (#9055) or the 4-port 1GbE Adapter (#5899)
- Service Processor
- Integrated SAS or SATA controller for HDD, SSD, tape, or DVD with RAID 10 support in system unit; RAID 5 and 6 available
- 3 system ports and three USB ports
- 3 Hardware Management Console (HMC) ports and two System Power Control Network (SPCN) ports
- Redundant and hot-swap power available
- Redundant and hot-swap cooling
- Half-high bay for tape or removable drive
Weight and Dimensions:
Rack-mount:
Width: 440 mm (17.3 in)
Depth: 610 mm (24.0 in)
Height: 173 mm (6.81 in)
Weight: 48.7 kg (107.4 lb)
Tower:
Width without tip plate: 183 mm (7.2 in)
Width with tip plate: 328.5 mm (12.9 in)
Depth : 688 mm (27.1 in)
Height: 541 mm (21.3 in)
Weight without tip plate: 53.7 kg (118.1 lb)
Weight with tip plate: 57.2 kg (125.8 lb)
Note: Weight varies based on configuration.
