Linux Server Hardware IBM POWER9 8335-GTH AC922
Brand:
IBM AS400 iSeries
Model Number:
8335-GTH-EP0R
The next generation of IBM Power Systems, with POWER9 technology, is built with innovations that deliver high speeds for the AI era. Our new Linux scale-out systems embrace acceleration for the next generation of datacenter computing and help provide differentiated performance, scalability, and potentially low acquisition cost.
Other 8335-GTH AC922 Processor Models include:
8335-GTH EP0R x 2 20-core AC922
8335-GTH EP0R 20-core AC922 IBM POWER9 Linux server hardware specifications:
Processor Feature: EP0R x2 20-core 2.9 GHz – Two Socket
Memory: 2 TB Maximum in 16 Main Storage Slots DDR4
IBM POWER9 Memory must be installed in pairs. 8x DIMMs in 2-socket or 4x DIMMs in 1-socket. Mixing of POWER9 memory features is not allowed. 170 GB/s peak memory BW per system in 2S system with 8x 2R RDIMMs single drop and running at 2667 Mb/s, 136 GB/s peak memory BW with all 16x RDIMMs populated, running 2133 Mb/s.
Internal Storage Bays for SSD and HDD: 2x SFF-4 Bays
Up to two 1 TB 7200 RPM SATA disk drives (#ELD0)
Up to two 2 TB 7200 RPM SATA disk drives (#ES6A)
Up to two 960 GB SATA SSD (#ELU4)
Up to two 1.92 TB SATA SSD (#ELU5)
Up to two 3.84 TB SATA SSD (#ELU6)
Up to two 2 TB 7200 RPM SATA disk drives (#ES6A)
Up to two 960 GB SATA SSD (#ELU4)
Up to two 1.92 TB SATA SSD (#ELU5)
Up to two 3.84 TB SATA SSD (#ELU6)
PCIe I/O Adapter Slots:
Two PCIe x16 4.0 LP slots, CAPI enabled
Two PCIe x16 4.0 LP slots, CAPI enabled
One PCIe x16 4.0 LP slot, CAPI enabled or one PCIe x8x8 shared 4.0 slot, CAPI enabled
One PCIe x4 4.0 LP slot
One PCIe x4 4.0 LP slot
I/O Ports:
One front USB 3.0 port and one rear USB 3.0 port
One front USB 3.0 port and one rear USB 3.0 port
RAS Features: Concurrent Maintenance disks and Redundant Hot plug Power
Power Requirements: 2200 W 200-240V/277V AC
Physical Dimensions and Weights:
Width: 443 mm (17.4 in.)
Depth: 850.9 mm (33.5 in.)
Height: 86 mm (3.4 in.)
Weight: 30 kg (66 lb)
Rack: 2U for 19-inch rack mount chassis
Width: 443 mm (17.4 in.)
Depth: 850.9 mm (33.5 in.)
Height: 86 mm (3.4 in.)
Weight: 30 kg (66 lb)
Rack: 2U for 19-inch rack mount chassis
Other Power9 Linux Server Hardware Models and Specifications:
9008-22L S922 1 or 2 Processors, 8-12 Cores, 4TB Memory
9183-22X IC922 1 or 2 Processors, 12-20 Cores, 2TB Memory
9006-12P LC921 1 or 2 Processors, 16-40 Cores, 1TB Memory
9006-22P LC922 1 or 2 Processors, 16-44 Cores, 1TB Memory
8335-GTH AC922 2 Processors, 16-20 Cores, 2TB Memory
8335-GTX AC922 2 Processors, 16-22 Cores, 2TB Memory
9009-41A S914 1 Processor, 4-8 Cores, 1TB Memory
9009-42A S924 1 or 2 Processors, 8-12 Cores, 4TB Memory
9009-22A S922 1 or 2 Processors, 4-10 Cores, 4TB Memory
9040-MR9 E950 2 or 4 Processors, 32-48 Cores, 2 Sockets, 16TB Memory
9040-MR9 E950 2 or 4 Processors, 32-48 Cores, 4 Sockets, 16TB Memory
9080-M9S E980 (1 Node) 32-48 Processors, 4 Sockets, 16TB Memory
9080-M9S E980 (2 Node) 64-96 Processors, 8 Sockets, 16TB Memory
9080-M9S E980 (3 Node) 96-144 Processors, 12 Sockets, 16TB Memory
9080-M9S E980 (4 Node) 128-192 Processors, 16 Sockets, 16TB Memory
9006-12P LC921 1 or 2 Processors, 16-40 Cores, 1TB Memory
9006-22P LC922 1 or 2 Processors, 16-44 Cores, 1TB Memory
8335-GTH AC922 2 Processors, 16-20 Cores, 2TB Memory
8335-GTX AC922 2 Processors, 16-22 Cores, 2TB Memory
9009-41A S914 1 Processor, 4-8 Cores, 1TB Memory
9009-42A S924 1 or 2 Processors, 8-12 Cores, 4TB Memory
9009-22A S922 1 or 2 Processors, 4-10 Cores, 4TB Memory
9040-MR9 E950 2 or 4 Processors, 32-48 Cores, 2 Sockets, 16TB Memory
9040-MR9 E950 2 or 4 Processors, 32-48 Cores, 4 Sockets, 16TB Memory
9080-M9S E980 (1 Node) 32-48 Processors, 4 Sockets, 16TB Memory
9080-M9S E980 (2 Node) 64-96 Processors, 8 Sockets, 16TB Memory
9080-M9S E980 (3 Node) 96-144 Processors, 12 Sockets, 16TB Memory
9080-M9S E980 (4 Node) 128-192 Processors, 16 Sockets, 16TB Memory
