3648-8204 - IBM i Model E8A 300 GB 15K RPM SAS Disk Drive

IBM i Power 6, 8204 (#3648) 300 GB 15K RPM SAS Disk Drive

300 GB Serial Attached SCSI (SAS) DASD device, in a carrier capable of providing Hot Swap support. Provides 300 GB of storage capacity. Supports the industry standard SAS interface. Can be used only in a drawer/system designed to support the SAS interface.

Characteristics:

Form Factor: 3.5" Form Factor, 1-inch drive

Cable included: No

External Interface: Standard SAS Dual Port

Rotational Speed: 15,000 RPM

Interface speed: 300 MB/sec.

Format: 512 Bytes/sector default; 528 Bytes/sector possible with reformat

Attributes provided: 300GB of Disk Storage mounted in a carrier

Attributes required: One SAS disk drive bay

For 8204-E8A: IBM i Power 6, 8204 (#3648)

Minimum required: 0

Maximum allowed: 582 (Initial order maximum: 250)

OS level required:

AIX 5.3 with the 5300-08 Technology Level, or later.

AIX 5.3 with the 5300-06 Technology Level and Service Pack 7, or later

AIX 5.3 with the 5300-07 Technology Level and Service Pack 4, or later

AIX 6.1 with the 6100-00 Technology Level and Service Pack 5, or later

SUSE Linux Enterprise Server 10 SP1 for POWER Systems, or later

Red Hat Enterprise Linux for POWER, version 4.5, or later

Red Hat Enterprise Linux for POWER, version 5.1, or later

Initial Order/MES/Both/Supported: Both

CSU: Yes

Return parts MES: No
