00LY161 IBM 59E9 00E8693 387GB 4K SFF-3 SAS Enterprise SSD ES0V ES0U
Brand:
IBM AS400 iSeries
Model Number:
00LY161-59E9
Custom Field 1 (UPC):
59E9
Custom Field 4 (MPN): 00LY161
Custom Field 4 (MPN): 00LY161
00LY161 IBM 59E9 387GB 4K SFF-3 SAS Enterprise SSD ES0V ES0U 00E8693
IBM 59E9 387GB 2.5-inch Enterprise SSD is formatted with 4K byte sectors for SFF-3 SAS bays of IBM i, Power AIX, Linux Servers and VIOS Power8 system unit, has 00LY161 part number and can have ES0V or ES0U feature codes. The IBM ES0V and ES0U feature codes, and are identical solid state drives that report with same 59E9 CCIN and have the same 00LY161 00E8693 part numbers. The different feature codes are used by IBM configuration tools to specify which OS type, drive format and carrier tray needed for ordering.
The IBM Power8 S814 8286-41A and S824 8286-42A servers support two new SSD features in the IBM EXP24S EL1S SFF Gen2-bay Drawer: 387 GB SFF-2 4k SSD for IBM i (59E8 00E8710 ES0R) and 775 GB SFF-2 4k SSD for IBM i (59C3 00E8713 ES0T). Also available are SSDs mounted in a Gen2 carrier as 387 GB SSF-3 4k SSD for IBM i (59E9 00LY161 ES0V) and 775 GB SFF-3 4k SSD for IBM i (59EB 00LY162 ES0X) for use in the CEC Gen3 bays. A new 528 byte, single-sided format disk, the 571 GB 15k RPM SAS SFF-3 Disk Drive (59CE 00E8653 ESDE), is available for use on S814 and S824 servers. The 00LY161 IBM 59E9 disk drive is also supported on Power7 servers as 571 GB 15K RPM SAS SFF-1 (59CE 00E8648 ESDJ) and as 571 GB 15K RPM SAS SFF-2 (59CF 00E8660 ESDN).
IBM Power8 and Power7 AIX and Linux eMLC3 SSD and Disk Drives:
177 GB 1.8-inch 4k SSD Read Intensive AIX 59BB 00LY175
177 GB 1.8-inch 528 byte SSD Read Intensive Linux 59BC 00LY181
387 GB SFF-2 4K SSD AIX 59E8 00E8710
387 GB SFF-2 4K SSD Linux 59E8 00E8710
387 GB SFF-3 4k SSD AIX Linux 59E9 00LY161
387 GB SFF-3 4k SSD Linux 59E9 00LY161
775 GB SFF-2 4k SSD AIX 59C3 00E8713
775 GB SFF-2 4k SSD Linux 59C3 00E8713
775 GB SFF-3 4k SSD AIX 59EB 00LY162
775 GB SFF-3 4k SSD Linux 59EB 00LY162
600 GB 15K RPM SAS SFF-1 Disk Drive 5xx Block AIX 59CE 00E8653
600 GB 15K RPM SAS SFF-1 Disk Drive 5xx Block Linux 59CE 00E8653
600 GB 15K RPM SAS SFF-2 Disk Drive 5xx Block AIX 59CF 00E8665
600 GB 15K RPM SAS SFF-2 Disk Drive 5xx Block Linux 59CE 00E8653
600 GB 15k RPM SAS SFF-3 Disk Drive 5xx Block AIX 59CE 00E8653
600 GB 15k RPM SAS SFF-3 Disk Drive 5xx Block Linux 59E4 00E9908
2 TB Removable Disk Drive Cartridge (RDX)
177 GB 1.8-inch 528 byte SSD Read Intensive Linux 59BC 00LY181
387 GB SFF-2 4K SSD AIX 59E8 00E8710
387 GB SFF-2 4K SSD Linux 59E8 00E8710
387 GB SFF-3 4k SSD AIX Linux 59E9 00LY161
387 GB SFF-3 4k SSD Linux 59E9 00LY161
775 GB SFF-2 4k SSD AIX 59C3 00E8713
775 GB SFF-2 4k SSD Linux 59C3 00E8713
775 GB SFF-3 4k SSD AIX 59EB 00LY162
775 GB SFF-3 4k SSD Linux 59EB 00LY162
600 GB 15K RPM SAS SFF-1 Disk Drive 5xx Block AIX 59CE 00E8653
600 GB 15K RPM SAS SFF-1 Disk Drive 5xx Block Linux 59CE 00E8653
600 GB 15K RPM SAS SFF-2 Disk Drive 5xx Block AIX 59CF 00E8665
600 GB 15K RPM SAS SFF-2 Disk Drive 5xx Block Linux 59CE 00E8653
600 GB 15k RPM SAS SFF-3 Disk Drive 5xx Block AIX 59CE 00E8653
600 GB 15k RPM SAS SFF-3 Disk Drive 5xx Block Linux 59E4 00E9908
2 TB Removable Disk Drive Cartridge (RDX)
00LY161 IBM 59E9 OS Requirements:
IBM V7R1 or higher
IBM i V7R2 & TR PTF Group SF99717 Level 1 C4276720 + HIPER PTF Group
IBM i V7R1 & TR9 (TR PTF Group SF99707 Level 9) C4283710 + HIPER PTF Group
IBM i V7R2 as a client of VIOS and TR1 (TR PTF Group SF99717 Level 1) with VIOS 2.2.3.4, C4276720 + HIPER PTF Group
IBM i V7R1 as a client of VIOS and TR9 (TR PTF Group SF99707 Level 9) with VIOS 2.2.3.4, C4283710 + HIPER PTF Group
AIX 6.1 and 7.1 or later
Red Hat Enterprise Linux
SUSE Linux Enterprise Server
IBM i V7R1 & TR9 (TR PTF Group SF99707 Level 9) C4283710 + HIPER PTF Group
IBM i V7R2 as a client of VIOS and TR1 (TR PTF Group SF99717 Level 1) with VIOS 2.2.3.4, C4276720 + HIPER PTF Group
IBM i V7R1 as a client of VIOS and TR9 (TR PTF Group SF99707 Level 9) with VIOS 2.2.3.4, C4283710 + HIPER PTF Group
AIX 6.1 and 7.1 or later
Red Hat Enterprise Linux
SUSE Linux Enterprise Server
Note: IBM 4k drives cannot be reformatted to 5xx drives (or vice versa). IBM is transitioning away from manufacturing SAS Hard Disk Drives (HDD) and Solid State Drives (SSD) formatted with 512 and 528 byte sector (5xx), and instead will only be providing 4K byte sector drives. Although most AIX and Linux applications will not experience issues since data access to the SAS drives is via a file system, companies should confirm with their application provider to ensure compatibility with using SSD or HDD with 4K byte sectors. AIX and Linux applications that require direct access to the raw data on the SSD or HDD, may require 512 and 528 byte sector (5xx) sectors drives.
