IBM FS5200 4662-6H2 FlashSystem Storage
The new IBM FlashSystem 5200 model 4662-6H2 is an enterprise flash storage delivering up to 1.2 PB per 1U enclosure, 21 GB/s bandwidth, 70 microseconds latency, 1.5 million IOPS response times and includes IBM Spectrum Virtualize software suite. The IBM FlashSystem has the highest customer satisfaction rating in the industry in 2022 in the Enterprise Class Flash Storage category according to TrustRadius. The IBM FS5200 model 4662-6H2 FlashSystem is among IBM's most affordable flash storage offerings, without compromising performance or sacrificing best in class features. Businesses of all sizes can now take advantage of the most advanced and secure IBM Flash Storage systems on the market, and achieve the same benefits as the largest data centers. The all new FlashSystem 5200 model 4662-6H2 delivers extreme performance options at an affordable price. View the IBM FS5200 peformance specifications below, or detailed benchmarks on the IBM FlashSystem 5200 product page or view the IBM FlashSystem comparison page for help sizing the correct IBM Flash Storage solution for your business.
IBM FlashSystem 5200 4662-6H2 Flash Storage Maximums and Specifications:
Max bandwidth: 21 GB/s throughput
Max Latency/IOPS Response times: 70 microseconds, 1.5 million IOPs
Clustered max bandwidth/IOPS Response times: 84 GB/s, 6 million IOPS
Max Cache per enclosure/cluster: 64 or 512 GB / 256 GB or 2.04 TB
Max capacity per 1U enclosure/expansion: 1.2 PB / 32 PB
Max Drives per system/cluster: 748/2,992
Scale out with 2-way clustering for up to 4 systems
Scale up to 20 2U expansion units or 8 5U expansion units for 32 PB
Software: IBM Storage Insights and IBM Spectrum Virtualize software suite that includes Data migration, Data Reduction Pools with thin compression, Deduplication, Thin Provisioning, UNMAP, Remote mirroring, Easy Tier and FlashCopy.
Max front end host ports: 8
Host interfaces: 10 Gbps Ethernet (iSCSI), 25/10 Gbps Ethernet (iSCSI, iSER—iWARP, RoCE v2), 16 Gbps Fibre Channel (FC, FC-NVMe), 32 Gbps Fibre Channel (FC, FC-NVMe), 12Gbps SAS
Supported Drive Types and Sizes:
NVMe IBM FlashCore Modules: 4.8 TB, 9.6 TB, 19.2 TB, or 38.4 TB
NVMe Industry-standard drives: 800 GB, 1.92 TB, 3.84 TB, 7.68 TB, 15.36 TB, and 30.72 TB
NVMe SCM drivess: 375 GB, 750 GB, 800 GB, 1.6 TB and 3.2 TB
10K SFF disk drives: 1.2 TB, 1.8 TB, and 2.4 TB
10K LFF disk drives: 1.2 TB, 1.8 TB, and 2.4 TB
7200 LFF Nearline disk drives: 4 TB, 6 TB, 8 TB, 10 TB, 12 TB, 14 TB, 16 TB, and 18 TB
Physical Dimensions: Heights is 3.4 in. (8.7 cm) | Width is 19 in. (48.3 cm) | Depth is 21.9 in. (55.6 cm) | Weight is 55-62 lbs (fully configured depending on drives)
Warranty: 1 year with 9 to 5 next business-day response (upgradeable)
Other IBM FlashSystem Models include:
IBM FlashSystem 5100 FS5015 2072-2N2 2072-2N4
IBM FlashSystem FS5100 FS5035 2072-3N2 2072-3N2
IBM FlashSystem FS7200 2076-824 2076-U7C
IBM FlashSystem FS7300 4657-924
IBM FlashSystem FS9500 4666-AH8
IBM FlashSystem FS9500R 4666-AH8
