IBM 2771 V.90 Two-port WAN IOA for iSeries AS400
IBM AS400 iSeries AS400 IBM 9406 LAN WAN, #4723 PCI 10MBPS ETHERNET IOA (#4723) PCI 10Mbps Ethernet IOA (Only available as REFURBISHED as of December 28, 2001)   The PCI.. Product #: 4723-9406

AS400 IBM 9406 LAN WAN, #4723 PCI 10MBPS ETHERNET IOA

Brand: IBM AS400 iSeries
Model Number: 4723-9406
Tags: 550

(#4723) PCI 10Mbps Ethernet IOA

(Only available as REFURBISHED as of December 28, 2001)



The PCI Ethernet IOA provides single attachment to one Carrier Sense Multiple Access/Collision Detect (CSMA/CD) LAN at 10Mbps. The feature consists of an adapter card and internal code which supplies Ethernet version 2 and IEEE 802.3 Media Access Control (MAC) plus IEEE 802.2 Logical Link Control (LLC) functions. The Ethernet/IEEE 802.3 IOA is capable of operating in half-or full-duplex mode.



#4723 has an RJ45 connector and a 15 pin D-Shell connector for attachment to customer supplied cabling. A vendor AUI Ethernet cable or RJ45 twisted pair cable must be ordered separately. #4723 cannot be used with #2790, PCI Integrated Netfinity Server.



PCI Card slots required: One.

Supported on the following systems: 270, 520, 550, 570, 595, 820, 810, 825, 830, 840, 870, 890, SB2, SB3
