AS400 IBM 9406 LAN WAN, #2742 PCI Two-Line WAN IOA

(#2742) PCI Two-Line WAN IOA

#2742 is a WAN IOA which supports up to two multiple protocol communications (RVX) ports when

one or two of the following cables are attached:

#0348 - V.24/EIA232 20-Ft PCI Cable

#0349 - V.24/EIA232 50-Ft PCI Cable (Only available as REFURBISHED)

#0353 - V.35 20-Ft PCI Cable

#0354 - V.35 50-Ft PCI Cable (Only available as REFURBISHED)

#0356 - V.36 20-Ft PCI Cable

#0359 - X.21 20-Ft PCI Cable

#0360 - X.21 50-Ft PCI Cable (Only available as REFURBISHED)

#0365 - V.24/EIA232 80-Ft PCI Cable (Only available as REFURBISHED)

#0367 - Operations Console PCI Cable

Note: The #0367 cable ships with a 25 pin to 9 pin adapter.

Multiple #0367 cables may be ordered (but only one per #2742) to serve as consoles for secondary

partitions when Logical Partitioning (#0140) is specified.

When #2742 is selected to support ECS, one of following cables must be specified:

#0348 V.24/EIA232 20-Ft PCI Cable

#0349 V.24/EIA232 50-Ft PCI Cable (Only available as REFURBISHED)

#0365 V.24/EIA232 80-Ft PCI Cable (Only available as REFURBISHED)

#2742 does not support remote power-on.

Supported on the following systems: 270, 520, 550, 570, 595, 800, 810, 820, 825, 830, 840, 870, 890, SB2, SB3
