7841-8205 - IBM i Series E4B, Ruggedize Rack Kit

IBM i Series 8205-E6B (#7841) - Ruggedize Rack Kit

For enhanced rigidity and stability of the rack, the optional Ruggedized Rack Kit provides additional hardware that reinforces the rack and anchors it to the floor. This hardware is designed primarily for use in locations where earthquakes are a concern. The feature includes a large steel brace or truss that bolts into the rear of the rack. It is hinged on the left side so it can swing out of the way for easy access to the rack drawers when necessary. The Ruggedize Rack Kit also includes hardware for bolting the rack to a concrete floor or a similar surface, and bolt-in steel filler panels for any noccupied spaces in the rack.

Attributes provided: Rear brace, bolt down hardware, bolt in frontfiller panels

Attributes required: #0551 19 inch 1.8m Rack or #0553 19 inch 2.0MRack

For 8202-E4B: (#7841)

Minimum required: 0

Maximum allowed: 12 (Initial order maximum: 0)

OS level required: None

Initial Order/MES/Both/Supported: Supported

CSU: Yes

Return parts MES: Does not apply
