Lenovo System x3750 M4

Ultra-Dense Design

The System x3750 M4 is optimized for performance and price. The server supplies support for up to 4 sockets and 48 DIMMs. This flexible server allows for the mixing and matching of internal storage. Extensive I/O bandwidth prevents bottlenecks. This affordable and scalable solution offers pay-as-you-grow processing.

System x3750 M4

A dense 4-socket 2U rack server with advanced flexibility and expandability.

Packed With Performance Power

• Incorporates outstanding features and capabilities in an ultra-dense design.
• Offers advanced flexibility and expandability to meet changing business requirements.
• Balances processing power, memory, and I/O bandwidth to optimize productivity and performance.
• Facilitates easy deployment, integration, service, and management.

Ultra-Dense Design

With a dense 2U design, the Lenovo® System x3750 M4 provides advanced features and capabilities. These include support for up to 4 sockets and 48 DIMMs, mix and match internal storage, up to 16 HDDs or 32 1.8-inch solid state drives (SSDs), 6 hot-swap, dual-rotor fans, and 2 power supplies. A Mezzanine LOM socket provides a choice of 1 Gigabit Ethernet (GbE) or 10 GbE networking options. Predictive Failure Analysis and light path diagnostics proactively monitor the system’s subcomponents and provide advanced warning on power supplies, fans, VRMs, disks, processors, and memory.

Pay as You Grow

The x3750 M4 blends outstanding flexibility and expandability. The unique 2+2 socket design enables pay-as-you-grow processing and memory expansion to help lower cost and manage growth. The 5+3 PCIe socket design allows you to pay for I/O capabilities as needed. The x3750 M4’s capabilities and performance enable clients to reduce total cost of ownership (TCO) by consolidating multiple 2-socket servers into fewer 4-socket x3750 M4 servers.

Simplify Provisioning and Systems Management

Simplify, automate, and modernize Day 1 provisioning and ongoing administrative tasks over the server life cycle with Lenovo XClarity.

Tech Specs

Form factor/height: 2U Rack

Processor: Up to four 4-, 6- 8-,10-or 12-core Intel Xeon processors E5-4600 v2 series

Processors: 2/4

Cache: Up to 30 MB per processor

Memory: Up to 1.5 TB via 48 slots with 32 GB LR-DIMM

Expansion slots: Five x8 low-profile PCIe Gen3 slots. Optional expansion riser adds three (x8) full-height/half-length PCIe Gen3 slots or 1 (x16) and 1 (x8) full-height//half- length PCIe Gen3 slots.

Media bays: Optional DVD drive

Disk bays (total/hot-swap): Up to sixteen 2.5-inch HDDs or up to thirty-two 1.8-inch eXFlash SSDs*

Internal storage: Up to 19.2 TB (2.5-inch HDDs) or 25.6 TB (SSDs) maximum

Network interface: Mezzanine LOM socket providing choices of 1 GbE and 10 GbE networking. 8 additional PCIe slots

Power supply: 750 W (DC), 900 W or 1400 W (1 standard, 2 maximum)

Hot-swap components: Fan modules, hard disk drives, eXFlash SSDs, power supply

RAID support: ServeRAID-M5210e RAID on motherboard, with Gen3 SAS controller. RAID-0, -1, -10 (standard) with -5, -50 and -6, -60 upgrades

Systems management: IMM2 with remote presence, Predictive Failure Analysis, Diagnostic LEDs, light path diagnostics panel, Automatic Server Restart, IBM Systems Director Active Energy Manager

USB ports: 2 front/2 back/2 internal

VGA ports: 1 front/1 back

Operating systems supported: Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSphere

Limited warranty: 3-year customer replaceable unit and on-site limited warranty, next business day 9x5, service upgrades available
