IBM 2724 PCI 16/4Mbps Token-Ring IOA for IBM iSeries AS400 PN: 90H9070

(#2724) PCI 16/4Mbps Token-Ring IOA

The PCI 16/4Mbps Token-Ring IOA provides a single attachment to either a 16Mbps or a 4Mbps IBM Token-Ring Network. The feature consists of an IOA card, internal code which supplies IEEE 802.5 Media Access Control (MAC) and IEEE 802.2 Logical Link Control (LLC) functions. The 16/4 Token-Ring IOA is capable of operating in half-or full-duplex mode.

#2724 includes a 2.44 meter (8-foot) token-ring cable. Alternatively, the customer can attach a separately purchased twisted pair cable to the RJ45 connection on the IOA. The standard IBM Cabling System patch cables can increase the length where necessary.

If #2724 or #9724 is selected to run on #6617 or #6618, then #0220 (Token-Ring on IPCS) is required for each #2723.

Prerequisites: One of the following:

#6617 or #6618 SPD card

PCI slot with required #2824 or the base controller in #5065/#5066 tower

PCI slot with required base controller in #503X Migration Tower I, or #9364/#5064 with #9329 or #9330.

PCI slots used: One.

Supported on the following systems: 150, 170, 250, 270, 400, 40S, 500, 50S, 510, 530, 53S, 600, 620, 640, 650, 720, 730, 740, 810, 820, 825, 830, 840, 870, 890, S10, S20, S30, S40, SB1, SB2, SB3
