AS400 IBM 9406 LAN WAN, #4745 PCI WAN IOA

(#4745) - PCI Two-Line WAN IOA

(Only available as REFURBISHED as of June 1, 2006)

#4745 supports up to two multiple protocol communications ports using the following cables:

#0348 V.24/EIA232 20-Ft PCI Cable (default)

#0353 V.35 20-Ft PCI Cable

#0355 V.35 80-Ft PCI Cable

#0356 V.36 20-Ft PCI Cable

#0358 V.36 150-Ft PCI Cable

#0359 X.21 20-Ft PCI Cable

#0367 Operations Console PCI Cable

A maximum of one #0367 can be ordered on a #4745 to serve as a console for a secondary partition when LPAR is implemented. PCI Card slots required: One.

When the #4745 is selected to support ECS, the following cable must be specified:

#0348 V.24/EIA232 20-Ft PCI Cable (default)

For 9406 - 520 (4745)

Minimum required: 0

Maximum allowed: 88 (Initial order maximum: 0 )

OS level required: i5/OS V4R5, or later

Initial Order/MES/Both/Supported: MES

CSU: Yes

Return parts MES: No

Note: This feature is supported for conversion only on the model 520, and cannot be ordered.

Supported on the following systems: 270, 520, 550, 570, 595, 810, 820, 825, 830, 840, 870, 890, SB2, SB3
