7840-8205 - IBM i Series E4B, Side-by-Side for 1.8m Racks

IBM i Series 8205-E6B (#7840) - Side-by-Side for 1.8m Racks

This feature allows a row of racks without side panels to be bolted together in a continuous suite, using the provided side to side rack connecting hardware. When multiple racks are joined in this way, cables can be easily run between racks without having to exit the continuous rack enclosure. A small gap is maintained between the two adjacent racks, which is filled by three matching steel trim pieces that snap into place on the front, top, and rear, between each rack. The trim pieces cover the space between each rack for an enhanced appearance and for additional protection of the equipment inside the racks. Side panels are needed only for the two end racks of the suite.

Attributes provided: Hardware and trim to attach two racks

Attributes required: #0551 rack

For 8202-E4B: (#7840)

Minimum required: 0

Maximum allowed: 12 (Initial order maximum: 0)

OS level required: None

Initial Order/MES/Both/Supported: Supported

CSU: Yes

Return parts MES: Does not apply
