5785-8205 - IBM i Series E4B, 4 Port Async EIA-232 PCIe Adapter

IBM i Series 8205-E6B (#5785) - 4 Port Async EIA-232 PCIe Adapter

Connection for 4 asynchronous EIA-232 devices. Ports are programmable to support EIA-232 protocols, at a line speed of 128K bps.

Attributes provided: 4-Port Asynchronous EIA-232 via 4-Port DB9 DTE Fan-Out Cable 1.2 M (4 ft.), 4 x 9-pin D-Sub (Male DB-9) and 1 x 68-pin D-Sub (HD-68)

Attributes required: 1 PCIe Slot

For 8202-E4B: (#5785)

Minimum required: 0

Maximum allowed: 24 (Initial order maximum: 24)

OS level required:

AIX Version 5.3 supported

AIX Version 6.1 supported

AIX Version 7.1 supported

SUSE Linux supported

Red Hat Linux supported

Refer to Software Requirements for specific O/S levels supported

Initial Order/MES/Both/Supported: Both

CSU: Yes

Return parts MES: No

Note:

Maximum of 4 in the CEC

System maximum of 24 -- 4 in CEC and 20 in 2 x #5802/ #5877
