1986-8205 - IBM i Series E4B, 1 Gigabit iSCSI TOE PCI-X on Coppe

IBM i Series 8205-E6B (#1986) - 1 Gigabit iSCSI TOE PCI-X on Copper Media Adapter

The 1 Gigabit iSCSI TOE PCI-X adapter encapsulates SCSI Commands and data into TCP and transports them over the Ethernet via IP packets. The adapter operates as an iSCSI TOE (TCP/IP Offload Engine). This offload function eliminates host protocol processing and reduces CPU interrupts. Adapter uses RJ45 Gigabit Ethernet connector.

Attributes provided: Offload of host protocol processing

Attributes required: Available PCI-X Slot

For 8202-E4B: (#1986)

Minimum required: 0

Maximum allowed: 24 (Initial order maximum: 0)

OS level required:

AIX Version 5.3 supported

AIX Version 6.1 supported

AIX Version 7.1 supported

SUSE Linux supported

Red Hat Linux supported

Refer to Software Requirements for specific O/S levels supported

Initial Order/MES/Both/Supported: Supported

CSU: Yes

Return parts MES: Does not apply

Note:

Not supported in the CEC

System maximum of 24 in 4 x #5796
