VTL Backup Appliance VTL Backup Appliance iSAN-V2 VTL backup appliance with up to 24 disk bays, delivers up to 1.5 GB/s transfer rates,&nbsp.. Product #: VTL-Backup-iSANV2

VTL Backup Appliance iSAN-V2

Brand: VTL Backup Appliance
Model Number: VTL-Backup-iSANV2

VTL backup appliance with up to 24 disk bays, delivers up to 1.5 GB/s transfer rates, capable of backing up 7.2 TB/hr to disk and scales to 144 TB. VTL backup appliance competitors like Unitrends, ExaGrid, EMC Data Domain, FalconStor, IBM and Quantum Virtual Tape Library solutions don't compare to Cybernetics VTL backup appliances on price, performance, options, scalability or standard features. Cybernetics VTL backup appliances can simultaneously write 16 concurrent parallel data streams from heterogeneous systems to VTL disk using existing backup software, including IBM iSeries & Power systems. VTL backup restores from an iSAN-V2 appliance are near-instantaneous. The iSAN-V2 models offer GbE (1 and 10GB), iSCSI, SAS, Fibre (8 and 16GB), eSATA, miniSAS, USB and legacy SCSI host/device interfaces. The iSAN's Post-Process deduplication can fit 1 TB backups into 20GB of VTL disk space. iSANs let you archive your backups from VTL disk to traditional tape or other devices without involving your servers, users or network (encryption optional). A Cybernetics iSAN-V2 VTL provides the ultimate value in performance, flexibility, options and security at a price competitors can't touch. All iSAN VTL's include Enterprise class features for site-to-site replication, tape virtualization, post-process data deduplication, unlimited virtual tapes, 16 virtual tape drives/libraries and offline archival support for tape libraries with up to 4 drives/48 slots. Many Cybernetics VTL customers that had a 24+ hour tape backup, now only takes an hour to backup.

Cybernetic VTL backup appliances are available in 100% pure SSD, SAS or hybrid-mix of SSD & SAS, and include:

iSAN-SSD VTL models (4 GB/s & 14 TB/hr)
iSAN-V2 SSD/SAS/Mixed VTL Models (1.5 GB/s & 7.2 TB/hr)
iSAN-V SAS VTL Models (1.2 GB/s & 4.2 TB/hr)
Entry
 miSAN-V SAS VTL models (500 MB/s & 1.8 TB/hr)

Note: All models provide option to Encrypt VTL disk, tape media and replication communication for complete security.

Cybernetics provides unlimited Support via phone & email for the Lifetime of the VTL device life, a 2 yr Warranty (covering all parts & labor costs). Cybernetics provides optional Support plans including 24X7 support, advanced replacement and on-site support services.

Virtual Tape Library VTL Comparison

CYBERNETICS iSAN-V2-24 iSAN-V2-16 iSAN-V2-12 iSAN-V2-8
GbE Ports 8 +1 Mgmt 8 +1 Mgmt 8 +1 Mgmt 8 +1 Mgmt
miniSAS Ports 4 4 4 4
USB Ports 4 4 4 4
eSATA Ports 2 2 2 2
10 GbE Ports Optional Optional Optional Optional
SAS Ports Optional Optional Optional Optional
8GB Fibre Ports Optional Optional Optional Optional
16GB Fibre Ports Optional Optional Optional Optional
SCSI Optional Optional Optional Optional
Max Base Raw Capacity 144 TB 96 TB 72 TB 48 TB
Max Raw Capacity w/ Exp. 768 TB via 7 Exp. 720 TB via 7 Exp. 696 TB via 7 Exp. 672 TB via 7 Exp.
Disk Bays 24 (192 Max) 16 (184 Max) 12 (180 Max) 8 (176 Max)
RAID Levels 0, 1, 5, 6, 10, 50, 60 0, 1, 5, 6, 10, 50, 60 0, 1, 5, 6, 10, 50, 60 0, 1, 5, 6, 10, 50, 60
Max Transfer Rate 1.5 GB/s (7.2 TB/hr) 1.5 GB/s (7.2 TB/hr) 1.5 GB/s (7.2 TB/hr) 1.5 GB/s (7.2 TB/hr)
Deduplication Ratio 50:1 Typical 50:1 Typical 50:1 Typical 50:1 Typical
Offline Archive Included Included Included Included
Archiving to Tape Included Included Included Included
Thin Tape Provisioning Included Included Included Included
Deduplication Threshold Reset Included Included Included Included
Deduplication Process Post Process Post Process Post Process Post Process
Site-to-Site Replication Included Included Included Included
Encryption on VTL Disk Optional Optional Optional Optional
Encryption of Tape Media Optional Optional Optional Optional
Encryption of Replicated Data Included Included Included Included
Base Model Rack Space 2U to 4U 2U to 4U 2U to 4U 2U to 4U
Technical Support Lifetime, Unlimited Lifetime, Unlimited Lifetime, Unlimited Lifetime, Unlimited
Installation & Training Included Included Included Included
Onsite Services Optional Optional Optional Optional
Product Warranty 2 Yr RTF 2 Yr RTF 2 Yr RTF 2 Yr RTF
Software Updates 2 Yr 2 Yr 2 Yr 2 Yr
Platform Support IBM iSeries
IBM AIX
Windows
Linux
Unix
HP-UX
Netware
MAC OSX
IBM iSeries
IBM AIX
Windows
Linux
Unix
HP-UX
Netware
MAC OSX
IBM iSeries
IBM AIX
Windows
Linux
Unix
HP-UX
Netware
MAC OSX
IBM iSeries
IBM AIX
Windows
Linux
Unix
HP-UX
Netware
MAC OSX
Backup SW Support Any & All Any & All Any & All Any & All
