iSeries LAN WAN, #2824 PCI LAN/WAN/WORKSTATION IO

(#2824) PCI LAN/WAN/Workstation IOP

(Only available as REFURBISHED as of November 21, 2003)

Can be used for attaching disk and tape units, LAN, WAN, and workstation IOAs.

The following storage PCI adapters are supported:

#2718 PCI Magnetic Media Controller (Only available as REFURBISHED)

#2729 PCI Magnetic Media Controller (Only available as REFURBISHED)

#2748 PCI RAID Disk Unit Controller (Only available as REFURBISHED)

The following PCI communication adapters are supported:

#2721 PCI Two-Line WAN IOA

#2722 PCI Twinaxial Workstation IOA

#2723 PCI Ethernet IOA

#2724 PCI 16/4Mbps Token-Ring IOA

#2745 PCI Node WAN IOA (Only available as REFURBISHED)

#2746 PCI Node Twinaxial IOA (Only available as REFURBISHED)

#2750 PCI ISDN BRI U IOA

#2751 PCI ISDN BRI S/T IOA

#2761 PCI Integrated Analog Modem (Only available as REFURBISHED)

#2811 PCI 25Mbps UTP ATM

#2812 PCI 45Mbps Coax T3/DS3 ATM

#2815 PCI 155Mbps UTP OC3 ATM

#2816 PCI 155Mbps MMF ATM

#2818 PCI 155Mbps SMF OC3 ATM

#2819 PCI 34Mbps Coax E3 ATM

#2838 PCI 100/10Mbps Ethernet IOA (Only available as REFURBISHED)

#4800 PCI Cryptographic Coprocessor

#4802 PCI Cryptographic Coprocessor (Only available as REFURBISHED)

Some installation restrictions may apply. Use the configurator to ensure a valid configuration.

Prerequisites: One PCI controller slot. Maximums: One in the Migration Tower I, two in the #9330 PCI Integrated Expansion Unit, two in each #5065 Storage/PCI Expansion Tower, and four in each #5066, 1.8m I/O Tower.

Supported on the following systems: 170, 250, 600, 620, 640, 650, 720, 730, 740, 820, 825, 830, 840, S10, S20, S30, S40
