iSeries IBM 9406, #2865 PCI INTEGR. NETFINITY SERV
(#2865) PCI Integrated Netfinity Server
(Only available as REFURBISHED as of July 2, 2002)
Contains a 333MHz Pentium II processor, four main storage slots, and two LAN IOA slots. This adapter requires two reserved PCI card positions, one for the processor card and the second for a bridge card to interface the processor to the system.
Each memory card slot can contain a 32MB, 64MB,or 256MB memory card producing a total memory capacity ranging from 32MB to 1024MB. At least one memory card is required. The feature numbers for the memory cards are as follows:
#2861 32MB Server Memory
#2862 128MB Server Memory
#2867 256MB Server Memory (Only available as REFURBISHED)
Each LAN IOA slot can contain a PCI Token Ring IOA, a PCI Ethernet IOA or the PCI 100/10Mbps Ethernet IOA. The Integrated PC Server is capable of supporting two IOAs in any combination with a maximum of one 100/10Mbps Ethernet. At least one LAN IOA feature is required. The features for the LAN IOAs are as follows:
#2723 PCI Ethernet IOA
#2724 PCI 16/4Mbps Token-Ring IOA
#2838 PCI 100/10Mbps Ethernet IOA (Only available as REFURBISHED)
#9723 Base PCI Ethernet IOA (Only available as REFURBISHED)
#9724 Base PCI Token-Ring IOA (Only available as REFURBISHED)
#9738 Base PCI 100/10Mbps Ethernet (Only available as REFURBISHED)
If #2724 or #9724 is selected, then #0220 (Token-Ring on IPCS) is required for each #2724/#9724 selected to run on a #6617, #6618, #2854, or #2865.
If #2723 or #9723 is selected, then #0221 (Ethernet on IPCS) is required for each #2723/#9723 selected to run on a #6617, #6618, #2854, or #2865.
If #2838 or #9738 is selected to be run on a #6617, #6618, #2854, or #2865, then #0222 (100/10Mbps Ethernet on IPCS) is required for each #2838/#9838 selected.
If running NT operating system on #2865, then;
#0325 (IPCS Extension Cable for NT) is required
A minimum of 64MB is required. Maximum total memory is 1024MB.
#1700 (IPCS Keyboard/Mouse for NT) is default (in those countries offering it)
A display must be connected to the IPCS to support NT.
For supported keyboard/mouse and display types, see:
http://www.as400.ibm.com/nt
If running OS/2 operating system on #2865, then #0325 and #1700 and display are not allowed.
Maximum total memory is 512MB.
PCI card slots Required: None. Reserved positions exist in the base system unit and in the #9329/#9330 PCI Integrated Expansion Unit for the two cards used by this feature.
Maximums: One in the 503X Migration Tower I and one in the #9329/#9330 PCI Integrated Expansion Unit.
Supported on the following systems: 600, 620, 640, 650, 720, 740, 820, 830, S10, S20
