iSeries IBM 9406, #2751 PCI ISDN BRI S/T IOA
iSeries IBM 9406, #2811 PCI 25MBPS UTP ATM
IBM AS400 iSeries iSeries IBM 9406, #2761 PCI INTEGRATED ANALOG MODE (#2761) Integrated Analog Modem (Only available as REFURBISHED as of July 2, 2002)   #.. Product #: 2761-9406

iSeries IBM 9406, #2761 PCI INTEGRATED ANALOG MODE

Brand: IBM AS400 iSeries
Model Number: 2761-9406

(#2761) Integrated Analog Modem

(Only available as REFURBISHED as of July 2, 2002)



#2761 is the first in a family of new PCI IOAs based on the latest DSP technology. #2761 will allow the modem function to be integrated into the IOA and will support multiple analog modem port (eight phone lines).



Protocols supported:



SLIP/PPP

SDLC

Fax

Each #2761 includes eight 30-ft phone cables and a wrap cable/plug.



To the iSeries, #2761 looks like a single IOA with eight individual line resources available.



Prerequisites: #503X Migration Tower I, #5064/#9364, or #5065/#5066 tower with an available slot under a #2824 or base controller. Each #2761 counts as eight communication lines against the system maximums.

Supported on the following systems: 170, 250, 600, 620, 640, 650, 720, 730, 740, 820, 830, 840, S10, S20, S30, S40
