IBM 3581 H17 Ultrium 1 HVD SCSI 7 Slot Autoloader

The IBM 3581 Model H17 has seven cartridge slots, 0.7 TB data capacity (native), 1.4 data capacity (comp.), and one Ultrium tape drive. The H13 Model is equipped with a High-Voltage Differential (HVD) Ultra SCSI interface. 3581 H17 is technically identical to 3581 H13. IBM offered a standard 3 year warranty on the H13 and used a different model number to distinguish it from the H17 which only came with a 1 year warranty. IBM discontinued production of the H13 and H17 on 10/01/2004 so the manufacturer's warranty is no longer relevant.

Maximum data transfer rates are 15MB/Sec native and 30MB/Sec if 2:1 compression is achieved.



Additional options for this model are;

• Feature 7003 - Rack kit for 5U style IBM Autoloaders.
• Feature 7004 - Bar Code Reader

• LTO1 100/200GB Data Cartridges
• LTO Cleaning Cartridges.
• HD68-HD68 HVD SCSI Cables in 5.0m, 10.0m, 18.0m, and 25.0m lengths.

The 3581-H17 is supported by the following operating systems;

• OS/400 V4R4 or later (model H17)
• AIX Version 4.3.2 or later
• Sun Solaris 2.6, Solaris 7, Solaris 8
• Microsoft Windows NT 4.0 with Service Pack 6
• Microsoft Windows 2000, build 2195 or greater
• HP-UX 11.0 or later

The 3581 Model H17 can be attached to AS/400, RS/6000, RS/6000 SP, and non-IBM servers, workstations, and personal computers that support Ultra/Wide SCSI HVD interface specifications.

Weight and Dimensions

• Height: 19.0 cm (7.48 in) (5 EIA units if rack mounted)
• Width: 21.9 cm (8.62 in)
• Depth: 58.1 cm (22.87 in)
• Maximum Weight: 13.0 kg (28.7 lb)

Please contact Midland with any questions, for solution assurance, or for configuration assistance.
