7188-8203 - IBM Power6 E4A Power Distribution Unit

The IBM Power6 8203-E4A (#7188) Power Distribution Unit

An AC Power Distribution Unit (PDU) which mounts in a 19" rack and provides twelve C13 power outlets. The #7188 has six 16A circuit breakers, with two power outlets per circuit breaker. System units and/or expansion units must use a power cord with a C14 plug to connect to the #7188.

One of the following line cords must be used to distribute power from a wall outlet to the #7188;

#6489 - 14-Ft 3PH/24A Power Cord

#6491 - 14-Ft 1PH/63A Pwr Cord

#6492 - 14-Ft 1PH/48-60A Pwr Cord

#6653 - 14-Ft 3PH/16A Power Cord

#6654 - 14-Ft 1PH/24-30A Pwr Cord

#6655 - 14-Ft 1PH/24-30A WR Pwr Cord

#6656 - 14-Ft 1PH/32A Power Cord

#6657 - 14-Ft 1PH/24A Power Cord

#6658 - 14-Ft 1PH/24A Pwr Cd-Korea

Attributes provided: Power Distribution Unit withTwelve C13 power outlets.

Attributes required: none

For 8203-E4A: The IBM Power6 8203-E4A (#7188)

Minimum required: 0

Maximum allowed: No Max (Initial order maximum: 0)

OS level required: None

Initial Order/MES/Both/Supported: MES

CSU: Yes

Return parts MES: No
