7118-8202 - IBM Power7 E4B, Environmental Monitoring Probe

IBM Power7 8202-E4B (#7118) - Environmental Monitoring Probe

The Environmental Monitoring Probe (EMP) enables you to remotely monitor environmental conditions. Using a standard Web browser, you can view the ambient temperature and humidity of the remote environment, as well as the status of two additional contact devices, such as a smoke detector or open-door sensor. The temperature/humidity probe plugs into a RJ45 connector an a PDU+. The EMP can be used with any Powerware UPS equipped with a 10/100 Mb ConnectUPS Web/SNMP Card (firmware v3.01 or higher). The EMP can be located up to 20m (65.6 feet) away.

Attributes provided: Monitoring of temperature, humidity, and status of two contacts/ sensors. A one meter cat5 Ethernet cable, double sided velcro tape, two tie-wraps, and screw with wall anchor for mounting.

Attributes required: None

For 8202-E4B: (#7118)

Minimum required: 0

Maximum allowed: 9999 (Initial order maximum: 250)

OS level required: N/A

Initial Order/MES/Both/Supported: Both

CSU: Yes

Return parts MES: No

Note: Maximum support is 8x 7118 per 0553 rack and 8x 7118 per 0551 rack. Maximum of one 7118 per 7109 is supported.
