The IBM Power6 8203-E4A (#7109) Intelligent PDU+, 1 EIA Unit, Universal UTG0247 Connector

This feature is for an intelligent AC power distribution unit (PDU+) that will allow the user to monitor the amount of power being used by the devices that are plugged in to this PDU+. This AC power distribution unit provides twelve C13 power outlets. It receives power through a UTG0247 connector. It can be used for many different countries and applications by varying the PDU to Wall Power Cord, which must be ordered separately. Each PDU requires one PDU to Wall Power Cord. Supported power cords include the following features: #6489, #6491, #6492, #6653, #6654, #6655, #6656, #6657, and #6658.

Attributes provided: Twelve C13 outlets with Power Monitoring Capability

Attributes required: none

For 8203-E4A: The IBM Power6 8203-E4A (#7109)

Minimum required: 0

Maximum allowed: No Max (Initial order maximum: 0)

OS level required: None

Initial Order/MES/Both/Supported: MES

CSU: Yes

Return parts MES: No

Note: When purchased on an MES order with a feature code rack. This PDU will be mounted in the rear side pockets until all 4 side pockets on the rack have been filled. Any additional PDUs on the order will be mounted in 1 unit of EIA rack space. When purchased as an MES order for addition to a rack in the field. This PDU may not fit in the side pockets of your rack due to a hardware interference with the rack, and may require mounting in 1 unit of rack EIA space. Insure rack space is available before placing the MES order for this PDU when it is being ordered for field installation.
