IBM 7042-CR5 HMC Hardware Management Console  .. Product #: 7042-CR5

IBM 7042-CR5 HMC Hardware Management Console for Power Servers

Brand:
Model Number: 7042-CR5
Tags: 7042-cr5 , ibm hmc

IBM 7042-CR5 Hardware Management Console (HMC) is a dedicated-function appliance used to manage IBM i, AIX and Linux system resources running on Power8, Power7, Power6 and Power5 System service functions, logical partitions (LPARs), dynamic resource allocation and purchase Capacity on Demand Upgrades. The 7042-CR5 IBM HMC can manage multiple physically or logically (over a LAN) attached partitions and different Power Systems generations and OS400 Versions simultaneously, and can be physically attached to a server or logically attached over a LAN.

The IBM 7042-CR5 HMC also supports advanced service functions, including guided repair and verify, concurrent firmware updates for managed systems, and around-the-clock error reporting with Electronic Service Agent for faster support. The 7042-CR5 HMC management features can monitor and manage server utilization and enable simple provisioning of server resources that use PowerVM virtualization technology and temporary and permanent capacity on demand (CoD) activations. A IBM HMC is required for temporary CoD activation. An IBM HMC or the ASMI interface can be used for permanent CoD upgrades.

Compare the IBM 7042-CR5 specifications, features and HCM Code support with other IBM Hardware Management Consoles on our blog post. The 7042-CR5 HMC has the following standard hardware attributes:

2.4 GHz Intel Quad-core processor with 8 MB cache
4 GB (4x1GB) of DDR3 system memory
300 GB hot-swap SATA SFF HDD
SATA CD/RW - DVD-RAM
One SAS port, rear
Two video ports, one front and one rear
Four integrated Ethernet ports
Four USB ports, two front and two rear
One PCI-X slot
One PCIe slot

7042-CR5 IBM HMC Physical specifications

Height: 43 mm (1.7 in)
Width: 440 mm (17.3 in)
Depth: 711 mm (28.0 in)
Weight: 15.6 kg (35.5 lb)
