5719-8204 - IBM i Model E8A IBM 10 Gigabit Ethernet-LR PCI-X Ada

IBM i Power 6, 8204 (#5719) IBM 10 Gigabit Ethernet-LR PCI-X Adapter

Offers 10 Gigabit Ethernet PCI-X based server connections over a maximum of 10 kilometers of 1310nm single-mode fiber optic cable. The adapter conforms to the IEEE 802.3ae standard. The adapter requires 9um single-mode fiber optic cables and uses a SC connector type for connecting into net-work infrastructure components like 10 Gigabit Ethernet switch/router with SC connectors.

Attributes provided: 10 Gigabit Ethernet connections

Attributes required: Available PCI-X slot

For 8204-E8A: IBM i Power 6, 8204 (#5719)

Minimum required: 0

Maximum allowed: 34 (Initial order maximum: 0)

OS level required: AIX 5.3 with the 5300-07 Technology Level or later. AIX 6.1 or later. SUSE Linux Enterprise Server 10 SP1 for POWER Systems, or later. Red Hat Enterprise Linux for POWER, version 4.5, or later. Red Hat Enterprise Linux for POWER, version 5.1, or later.

Initial Order/MES/Both/Supported: Supported

CSU: Yes

Return parts MES: Does not apply

Note: Maximum of two allowed in CEC under AIX or Linux.

System maximum of 34 under AIX or Linux.

Not supported under IBM i.
