5095-8203 - IBM Power6 E4A PCI-X Expansion Tower

The IBM Power6 8203-E4A (#5095) PCI-X Expansion Tower

The #5095 is a stand-alone (desk side) PCI-X Expansion Tower that provides expanded I/O capability for iSeries systems. The #5095 has seven PCI-X IOP/IOA slots and supports up to 12 disk units.

A #9844 Base PCI IOP is included with each #5095.

Note: With the availability of V5R4, #9844 is no longer included with #5095.

A bus adapter to provide the HSL interface to the system is required. Select one of the following:

#9517 - Base HSL-2 Bus Adapter, to specify two copper HSL-2 ports

#9876 - Base Optical Bus Adapter, to specify two optical HSL ports

Note: If ordered for a 9408-M25 or 9409-M50 a #6699 (RIO-2 Bus Adapter) must be ordered instead of a #9517 or #9876.

One or two HSL cables must be ordered with each #5095.

When ordering cables to connect to the HSL interface, optical HSL, copper HSL, copper HSL-2, or copper HSL to HSL-2 cables are required. An HSL loop uses all optical or all copper ports/cables. A copper loop can intermix I/O towers/units with copper HSL and copper HSL-2 ports. Select the appropriate cable based on the type of HSL ports to which it is being attached, and the cable length required.

The following HSL cables can be used with a #5095:

Copper HSL to HSL-2 (HSL on one end and HSL-2 on the other end)

#1474 - 6m HSL to HSL-2 Cable

#1475 - 10m HSL to HSL-2 Cable

#1487 - 3m HSL to HSL-2 Cable

Copper HSL-2 (HSL-2 on both ends of the cable)

#1307 - 1.75m HSL-2 Cable

#1308 - 2.5m HSL-2 Cable

#1481 - 1.2m HSL-2 Cable

#1482 - 3.5m HSL-2 Cable

#1483 - 10m HSL-2 Cable

#1485 - 15m HSL-2 Cable

Optical HSL (optical HSL connections on both ends of the cable)

#1470 - 6m HSL Optical Cable

#1471 - 30m HSL Optical Cable

#1472 - 100m HSL Optical Cable

#1473 - 250m HSL Optical Cable

One SPCN cable is required with each #5095. Select one of the following:

#1463 - 2m SPCN Cable

#1464 - 6m SPCN Cable

#1465 - 15m SPCN Cable

#1466 - 30m SPCN Cable

#0369 - 100m Optical SPCN Cable

#1468 - 250m Optical SPCN Cable

#6001 - 2m SPCN Cable

#6006 - 3m SPCN Cable

#6007 - 15m SPCN Cable

#6008 - 6m SPCN Cable

#6029 - 30m SPCN Cable

The #5095 has redundant power when feature #5138 is installed. The #5138 provides a second 435W power supply. In addition, when a #5138 is installed, a second line cord must be ordered. The presence of the #5138 and the second line cord, enables dual line cord capability.

Select one of the following line cords, or select two if #5138 is ordered:

#1394 - 4.3m 200V/10A Pwr Crd Brazil

#1395 - 4.3m 200V/10A Pwr Cd China

#1397 - 4.3m 200V/10A Pwr Crd Argent

#1398 - 4.3m 100V/10A Pwr Crd Brazil

#1410 - 200V 6-Ft Line Cord

#1411 - 200V 14-Ft Line Cord

#1412 - 125V 6-Ft Line Cord

#1413 - 125V 14-Ft Line Cord

#1414 - 200V 6-Ft Locking Line Cord

#1415 - 200V 6-Ft Watertight Line Cord

#1416 - 200V 14-Ft Locking Line Cord

#1417 - 200V 14-Ft Wtrtght Line Cord

#1422 - 3m IEC 320 C13/14 PDU Cord

#1438 - 4.3m 200V/10A Pwr Cd AU/NZ

#1439 - 4.3m 200V/10A Pwr Cd EU/Asia

#1440 - 4.3m 200V/10A Pwr Cd Denmark

#1441 - 4.3m 200V/10A Pwr Cd S Africa

#1442 - 4.3m 200V/10A Pwr Cd Swiss

#1443 - 4.3m 200V/10A Pwr Cd UK

#1444 - 4.3m 200V/10A Pwr Cd Italy

#1445 - 4.3m 200V/10A Pwr Cd Israel

#6458 - 14-Ft Int 250V/10A Pwr Cd

#6460 - 14-Ft 125V/15A Power Cord

#6469 - 14-Ft 250V/15A Power Cord

#6470 - 6-Ft 125V/15A Power Cord

#6471 - 9-Ft 125V/15A Power Cord

#6472 - 9-Ft 250V/16A Power Cord

#6473 - 9-Ft 250V/10A Power Cord

#6474 - 9-Ft 250V/13A Power Cord

#6475 - 9-Ft 250V/16A Power Cord

#6476 - 9-Ft 250V/10A Power Cord

#6477 - 9-Ft 250V/10A Power Cord

#6478 - 9-Ft 250V/16A Power Cord

#6479 - 9-Ft 250V/10A Power Cord

#6487 - 6-Ft 250V/15A Power Cord

#6488 - 9-Ft Dual Voltage Pwr Cd

#6493 - 9-Ft 250V/10A Power Cord

#6494 - 9-Ft 250V/10A Power Cord

#6495 - 9-Ft 250V/10A Power Cord

#6496 - 9-Ft 250V/10A Power Cord

#6497 - 6-Ft 250V/15A Power Cord

#6498 - 6-Ft 250V/15A Power Cord

#6651 - 9-Ft 127V/15A Power Cord

#6659 - 9-Ft 240V/15A Power Cord

#6660 - 14-Ft 127V/15A Power Cord

#6669 - 14-Ft 240V/15A Power Cord

#6670 - 6-Ft 125V/15A Power Cord

#6680 - 9-Ft 250V/10A Power Cord

#6687 - 6-Ft 250V/15A Power Cord

Attributes provided: 7 PCI slots and 12 disk positions

Attributes required: RIO-2 interface

For 8203-E4A: The IBM Power6 8203-E4A (#5095)

Minimum required: 0

Maximum allowed: 12(Initial order maximum: 0)

OS level required: IBM i V5R4 with V5R4M5 machine code, or later.

Initial Order/MES/Both/Supported: Supported

CSU: Yes

Return parts MES: Does not apply
