3679-8202 - IBM Power7 E4B, SAS Cable (AI)-Adapter to Internal d

IBM Power7 8202-E4B (#3679) - SAS Cable (AI)- Adapter to Internal drive 1M

(No Longer Available as of May 27, 2011)

This SAS cable (AI) connects a SAS Adapter to a bulkhead port for accessing internal SAS disks. It is 1 meter long. This cable has two Mini SAS 4x plug connectors, and is wired in 4x mode. Both ends are keyed for attachment to an end device.

Attributes provided: SAS 4x Cable

Attributes required: Feature to create the internal disk port

For 8202-E4B: (#3679)

Minimum required: 0

Maximum allowed: 9999 (Initial order maximum: 250)

OS level required: None

Initial Order/MES/Both/Supported: Both

CSU: Yes

Return parts MES: No
