3652-8203 - IBM Power6 E4A SAS Cable (EE-8203) Drawer to Drawer

The IBM Power6 8203-E4A (#3652) SAS Cable (EE) Drawer to Drawer 1M

SAS Cable (EE), connects a second SAS disk drawer to a primary SAS disk drawer attached to a SAS controller adaper. This cable has one Mini SAS 4x cable plug connector on each end. Both connectors must be attached to an ENCLOSURE UP Arrow port on the ESM module of the attaching drawers. Follow the directions on the connector labels when attaching the connectors on this cable. This cable supports both Single and Dual path configurations. All supported configurations require two of this feature to attach a secondary disk drawer to the primary disk drawer. The length of this cable is 1 meter. Choose the SAS (EE) cable length to match the distance between the two SAS drawers.

Attributes provided: SAS Disk drawer to SAS Disk drawer attach cable

Attributes required: Primary SAS Disk drawer properly configured

For 8203-E4A: The IBM Power6 8203-E4A (#3652)

Minimum required: 0

Maximum allowed: No max (Initial order maximum: No max)

OS level required: None

Initial Order/MES/Both/Supported: Both

CSU: Yes

Return parts MES: No
