3573-8247 IBM LTO5 Tape Autoloader

Ultrium 5 Half-high SAS Drive

This feature is a drive containing one IBM LTO Ultrium 5 Half-High SAS Tape Drive with a native 6 Gbps interface, which may be installed into a TS3100 or TS3200 Tape Library. Cables, ordered separately, are required to attach the TS3100 or TS3200 Tape Library to a host SAS adapter.

• Feature type: Chargeable
• Required feature: No
• Maximum number of features:
  • TS3100
    • One FH Drive (#8043, #8044, #8143, #8144, #8145, #8244, #8245)
    • Two HH Drives (#8046, #8047, #8147, #8247, #8248)
    • Drives can be intermixed
  • TS3200
    • Two FH Drives (#8043, #8044, #8143, #8144, #8145, #8244, #8245)
    • Four HH Drives (#8046, #8047, #8147, #8247, #8248)
    • Drives can be intermixed
• Installation: Plant or Field
• Limitations: When feature ADNR or ACY1 is present on order, the maximum quantity allowed is 99 and pre-requisite features are not applicable.

Part Number: 46X4394, 46X6073
