#3450 - IBM POWER8 SAS YO Cable 1.5m - HD 6Gb Adapter to Enclosure

(#3450) - SAS YO Cable 1.5m - HD 6Gb Adapter to Enclosure

This 1.5 meter SAS cable connects a SAS adapter to a SAS I/O enclosure. This YO cable has three connectors, one Mini-SAS HD (High Density)connector and two Mini SAS connectors. The Mini-SAS HD connector attaches to a SAS adapter such as the #5913 1.8GB RAID SAS Adapter. Both Mini SAS connectors attach to the same I/O drawer (enclosure) such as a #5887 EXP24S SAS I/O drawer. This cable can support up to 6Gb throughput.

Multiple cable length feature codes are available. Choose the cable length that best matches the distance between the adapter and the SAS I/O drawer.

• Attributes provided: connection between SAS adapter with Mini-SAS HD connectors and a SAS I/O drawer with Mini SAS connectors
• Attributes required: available connectors on SAS controller and SAS I/O drawer
• For 9119-MME: (#3450)
  • Minimum required: 0
  • Maximum allowed: 9999 (Initial order maximum: 250)
  • OS level required: None
  • Initial Order/MES/Both/Supported: Both
  • CSU: Yes
  • Return parts MES: No
