IBM AS400 iSeries #2758 HSL PORTS - 2 OPT/6 COPPER (#2758 / #9758) HSL Ports - 2 Optical/6 Copper(Only available as REFURBISHED as of October 1, 2004) .. Product #: 2758-9406

#2758 HSL PORTS - 2 OPT/6 COPPER

Brand: IBM AS400 iSeries
Model Number: 2758-9406

(#2758 / #9758) HSL Ports - 2 Optical/6 Copper

(Only available as REFURBISHED as of October 1, 2004)

Used in Model 830 with 4-way and 8-way processors, #2758/#9758 have six copper and two optical HSL ports and a 540MHz oscillator. One optics cleaning kit (P/N 46G6844) and instruction sheet are included per order.

#2758 is an optional feature. #9758 is a base bus expansion/clock card installed in the system unit of the 4-way and 8-way Model 830s.

This feature supports clustering on one of four available loops via HSL OptiConnect.

OS/400 V5R1 plus PTFs, or later, is required. For required PTF information, refer to Informational APAR II12949 at:

http://as400service.rochester.ibm.com/ supporthome.nsf/document/10000035

Supported on the following systems: 830
