2728-8203 - 4 port USB PCIe Adapter

The IBM Power6 8203-E4A (#2728) 4 port USB PCIe Adapter

The PCI-Express 4 port USB adapter provides support for USB devices. In applications that require the use of an USB extension cable, use one FC 4256 per port.

Attributes provided: Connectivity with USB 1.0 - 2.0 capable devices

Attributes required: One available PCI-Express slot

For 8203-E4A: The IBM Power6 8203-E4A (#2728)

Minimum required: 0

Maximum allowed: 3 (Initial order maximum: 3)

OS level required:

No IBM i support

AIX 5L for POWER version 5.3 with the 5300-09 Technology Level

AIX 5L for POWER version 5.3 with the 5300-06 Technology Level and Service Pack 10

AIX 5L for POWER version 5.3 with the 5300-07 Technology Level and Service Pack 7

AIX 5L for POWER version 5.3 with the 5300-08 Technology Level and Service Pack 5

AIX Version 6.1 with the 6100-02 Technology Level

AIX Version 6.1 with the 6100-00 Technology Level and Service Pack 7

AIX Version 6.1 with the 6100-01 Technology Level and Service Pack 3

SUSE Linux Enterprise Server 10 SP2 or later,

Red Hat Enterprise Linux 4.6 or later, and

Red Hat Enterprise Linux 5.2 or later

Initial Order/MES/Both/Supported: Both

CSU: Yes

Return parts MES: No

Note:

Maximum of 3 supported in CEC or system under AIX or Linux.

IBM i not supported.

AIX only supports USB 1.1

Feature 2728 requires system firmware level EM340 or later.
